SKF 1308 ETN9

B007VGCSV0

SKF 1308 ETN9 Double Row Self-Aligning Bearing, ABEC 1 Precision, Open, Plastic Cage, Normal Clearance, Metric, 40mm Bore, 90mm OD, 23mm Width

SKF 1308 ETN9 Double Row Self-Aligning Bearing, ABEC 1 Precision, Open, Plastic Cage, Normal Clearance, Metric, 40mm Bore, 90mm OD, 23mm Widthzoom

Attributes

Key Value
ABEC Tolerance1
Bearing MaterialSteel
Bearing TypeBall
Bore1.575 Inch | 40 Millime.
Bore Dia.40 mm
Bore Diameter40 mm
Bore Diameter Tolerance+0/-0.012 mm
Bore Tolerance+0/-.012mm
Bore TypeCylindrical
Cage MaterialPolyamide, PA66
Category - BDISelf Aligning Ball Bear.
Closure TypeNone
EAN7316576620720
EnclosureOpen
Fillet Radius1 mm
Harmonized Tariff Code8482.10.50.68
Inch - MetricMetric
Industry Number1308-ETN9
Inner Diameter40 mm
Inner Race Width0.906 Inch | 23 Millime.
Internal ClearanceC0-Medium, CN
ItemSelf-Aligning Ball Bear.
Keyword StringSelf Aligning
Long Description40MM Bore; Shaft Mount;.
LubricationShell Alvania Grease
Manufacturer Item Number1308 ETN9
Manufacturer NameSKF
Max. Load Axial620 lb
Max. RPM9,500 RPM
Minimum Buy QuantityN/A
Mounting MethodShaft
NounBearing
Number of RowsDouble
Number of Rows of BallsDouble Row
Other FeaturesAllowable Misalignment .
Outer Diameter90 mm
Outer Race Width0.906 Inch | 23 Millime.
Outer Ring Width23 mm
Outside Dia.90 mm
Outside Dia. Tolerance+0/-.015mm
Outside Diameter3.543 Inch | 90 Millime.
Outside Diameter Tolera.+0/-0.015 mm
Overall Width23 mm
Precision ClassABEC 1 | ISO P0
Product Group - BDIB00152
Rolling ElementBall Bearing
Seal/Shield TypeOpen
Single Row/Double RowDouble Row
Static Load Capacity2,520 lb
Static Load Rating11.21 kN
Temp. Range-40 Degrees to 210 Deg.
UNSPSC31171532
UPC Code7316576620720
Weight / Kilogram0.68
Weight / LBS1.499
Width23 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
RS Delivers209-180240.6921In StockSKF40.692 @ 1
thumbzoomAmazonB007VGCSV089.611In StockSKF89.61 @ 1
thumbzoomBDI Express1418525112.419991971In StockSKF1.496112.41999197 @ 1
us.rs-online.com73219222143.11In StockSKF Bearings143.1 @ 1
thumbzoomZoroG9418455154.991In StockSkf1.56154.99 @ 1
motionindustries.com00042945190.791In StockSKF190.79 @ 1
