| Air Cylinder Bore Dia., Bore Dia. | 25 mm |
| Air Cylinder Mount, Mount | Nose |
| Air Cylinder Type, Cylinder Type | Rodless |
| Body Material, End Cap Material | Aluminum |
| Country of Origin (subject to change) | Japan |
| Cushion Type | Rubber Bumper |
| Cylinder Action, Single Acting/Double Acting | Double Acting |
| Dimension A, Overall Length | 737 mm |
| Dimension B | 46mm |
| Dimension C | 13mm |
| Features | Magnetically Coupled, Rubber Cushions |
| Finish | Hard Coat Anodized |
| Item | Air Cylinder |
| Magnetic Piston | No |
| Max. Pressure | 102 psi |
| Nose Mount Thread | M26 x 1.5 in |
| Piston Material | Non-Magnetic |
| Port Size | 1/8 in NPT |
| Stroke | 600 mm |
| Temp. Range | 14 Degrees to 140 Degrees F |
| Tie Rod Material | N |
| Tube Material | Stainless Steel |
