| Air Cylinder Bore Dia., Bore Dia. | 20 mm |
| Air Cylinder Mount, Mount | Basic |
| Air Cylinder Type | Round Body |
| Body Material, End Cap Material, Tube Material | Aluminum |
| Country of Origin (subject to change) | China |
| Cushion Type | Air Cushion |
| Cylinder Action, Single Acting/Double Acting | Double Acting |
| Cylinder Type | Round |
| Dimension A | 5 4/5 in |
| Dimension B | 0.94 in |
| Dimension C | 1 in |
| Features | Adjustable Air Cushion |
| Finish | Hard Coat Anodized |
| Item | Air Cylinder |
| Magnetic Piston | Yes |
| Max. Pressure | 145 psi |
| Overall Length | 5.8 in |
| Piston Material | Magnetic |
| Piston Rod Material | Chrome Plated Carbon Steel |
| Port Size | 1/8 in NPT |
| Rod Dia. | 0.315 in |
| Rod Thread Length | 0.5 in |
| Rod Thread Size | 1/4"-28 UNF |
| Stroke | 2 in |
| Temp. Range | 14 Degrees to 140 Degrees F |
| Tie Rod Material | N |
