Square D

B09RPJNP9T

Square D - BJL36015LU - Molded Case Circuit Breaker, 15 A Amps, Number of Poles 3, Series BJL

Square D - BJL36015LU - Molded Case Circuit Breaker, 15 A Amps, Number of Poles 3, Series BJLzoom

Attributes

Key Value
9 Mm Pitches9
[Ics] Rated Service Bre.100 kA 220...240 V AC 5.
[Ue] Rated Operational .690 V AC 50/60 Hz UL 489
[Ui] Rated Insulation V.800 V IEC 60947-2
[Uimp] Rated Impulse Wi.8 kV IEC 60947-2
AC Voltage Rating690V AC
Ambient Air Temperature.-25-70 ?C
Ambient Air Temperature.-50-85 ?C
Amps15 A
Applicationdistribution
Awg GaugeAWG 6...AWG 2/0 fine st.
AWG RangeAWG 6...AWG 2/0 fine st.
BrandSquare D by Schneider E.
Breaking Capacity100 kA 208Y/120 V AC 50.
Breaking Capacity CodeJ
California Proposition .Cancer and Reproductive.
Catalog NumberBJL36015LU
China Rohs RegulationProduct out of China Ro.
Circuit Breaker Actuatortoggle
Circuit Breaker Applica.HACR rated
Circuit Breaker Mountin.Unit Mount
Circuit Breaker TypeStandard
ColorGray RAL 7016, Gray RAL.
Color FamilyGray
ConnectionAWG 6...AWG 2/0 fine st.
Connection Pitch27 mm
Continuous Current Rati.80 %
Control Typetoggle
Country of OriginUnited States, US - Uni.
Current Rating15-15A
Curve TypeB
DC Voltage RatingNot Rated
Depth3.15 in, 80 mm
Device Applicationdistribution
Device Short NameBJ 015
DisplayBJL36015LU Circuit brea.
ECCNEAR99
Electrical ConnectionEverlink lug line || Ev.
Electrical Durability10000 cycles IEC 947-1 .
Environmental DisclosureENVPEP1610005EN
Eu Rohs DirectiveCompliant
For Use WithElectrical Distribution.
Frame Size125A/BJ
Halogen Content Perform.Halogen free product
Height5.39 in, 137 mm, 5.39
Ik Degree Of ProtectionIK07 IEC 62262
Instantaneous TripFixed
Ip Degree Of Protectionfront cover IP40 IEC 60.
ItemMolded Case Circuit Bre.
Item Typecircuit breaker
Length20 mm, 3.15
Length UOMInch
Line Rated Current15-15 A
Local Signallingpresence of auxiliary c.
Made in USAYes
ManufacturerSchneider Electric
Max. AIR Rating100kA at 120/240V AC
Max. Wire Size2 AWG, 3 AWG
Mechanical Durability15000 cycles IEC 947-1 .
Mercury FreeYes
Min. Wire Size14 AWG, 6 AWG
MountingClip-On
Mounting Modeclip-on 35 mm symmetric.
Mounting TypeClip-On
Net Weight1.074 kg
Network Frequency50/60 Hz
No. of Poles3-Pole
Number of Poles3
Number Of Slots1 auxiliary switch OF p.
Operating Altitude6561.68 ft (2000 m) wit.
Phase ConnectionABC
Poles Description3P
Pollution Degree3 IEC 60947-1
Product CertificationsUL || IEC || CCC || EAC.
Product NamePowerPact B
Product Or Component Ty.circuit breaker
Protected Poles Descrip.3t
Pvc FreeYes
Quality LabelsCE
Quantity Per Setset of 1
RangePowerPact
Rated Voltage690V AC 50/60 Hz UL 489
Reach RegulationReference contains Subs.
Rohs Exemption Informat.Yes
SeriesBJL
StandardNMX J-266 || EN/IEC 609.
StandardsCSA C22.2 No 5, EN/IEC .
Sub BrandBJ 015
Suitability For Isolati.yes IEC 60947-2
Sustainable Offer StatusGreen Premium product
Terminal ConnectionEverlink Lug Both Ends
Tightening Torque5-5 N.m 2.5-16 mm? (AWG.
Torque5-5 N.m 2.5-16 mm? (AWG.
Trip TypeThermal Magnetic, therm.
Trip Unit NameTM-D
Trip Unit Technologythermal-magneticTM-D,
UNSPSC39121616
Utilisation Categorycategory A
WeeeThe product must be dis.
Width3.19, 81 mm, 3.19 in
Wire Stripping Length20 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomgordonelectricsupply.comBJL36015LU1015.01In Stock10SQUARE D1015.0 @ 1
thumbzoommayerelectric.comSQDBJL36015LU1181.971In StockSQUARE D2.36281181.97 @ 1
Newark16AC92661207.411In StockSQUARE D BY SCHNEIDER ELECTRIC1207.41 @ 1
thumbzoomZoroG63225611277.991In StockSquare D1277.99 @ 1
steinerelectric.comPDW~123149701865.01In StockSquare D?1865.0 @ 1
thumbzoomcrescentelectric.com6404541925.271In StockSquare D by Schneider Electric1925.27 @ 1
Graybar258620172071.91041In StockSquare D (Schneider Electric)2071.9104 @ 1
