Square D EDB14020 Circuit Breaker 20 AMP, 277 Volt, Single Pole

Square D EDB14020 Circuit Breaker 20 AMP, 277 Volt, Single Polezoom

Attributes

Key Value
AC Voltage Rating277V AC
Amperage20A
Amperage Rating20
Amps20 A
ApplicationHID rated Applications,.
ApprovalUL Listed, CSA Certifie.
ApprovalscULus
Auxiliary SwitchNo
AWG RangeAWG 12...AWG 6 aluminiu.
BrandSquare D, Square D by S.
Catalog NumberEDB14020
Circuit Breaker ActuatorToggle
Circuit Breaker Mountin.Bolt On, Bolt-On
Circuit Breaker TypeStandard
ColorBlack
Compatible Panelboard/L.NF
ConnectionLugs aluminium;AWG 12...
Country of OriginMX - Mexico, Mexico
Current Rating20A, 20 A
Current Stock3
DC Voltage RatingNot Rated
Depth4.05 in., 4.05 in
ECCNEAR99
Family SeriesSquare D Circuit Breake.
For Use WithSquare D NF Panelboards
FrameE-Frame
Frame Size125A/EDB
Frame TypeE-Frame
Gross Weight1.35 lbs
Gtin785901425045
Height5.66 in, 5.66 in., 5.66
Height UOMInch
International ShippingNo
Interrupt Rating18KA, 18 kA
ItemMiniature Circuit Break.
Item NumberEDB14020
Item TypeMiniature circuit-break.
kAIC @ 120 VAC25
kAIC @ 240 VAC18
kAIC @ 277 VAC18
Lead TimeExpected to ship in 1-2.
Length5.66 in, 4.05
Length (Straight Wirewa.5.66 in
Length UOMInch
Made in USANo
ManufacturerSquare D, Schneider Ele.
Manufacturer Part Number536577
Max Voltage277 VAC
Max. AIR Rating18 kA at 120/240V AC, 1.
Max. Operating Temp.104 Degrees F
Max. Wire Size6 AWG
Min. Wire Size12 AWG (Al), 14 AWG (Cu)
MountingBolt On, Panel
Mounting TypeBolt-On
MpnEDB14020
Net Weight1.045 lbs
Neutral PoleNo
No. of Spaces1
Number of Poles1
Operating Temperature40 A Degrees C
OverloadThermal/Magnetic
Phase1, Single
Poles1
Product SeriesE-Frame
ProtectionBranch Circuit
Rated Voltage277V AC
SeriesEDB, EDB Series
Shunt TripNo
SKUZO-G3369773
Special FeaturesTrip indicator
StandardUL LISTED - CSA CERTIFI.
StandardscULus, IEC
Sub BrandEDB
SubCategoryElectrical
Terminal ConnectionLug
Terminal TypeBox Terminal
Terminals IncludedLine and Load
Torque3.4-3.4 N.m 2.5-16 mm? .
Trip Range875 AMPS
Trip TypeThermal-magnetic, Therm.
Trip UnitFixed Thermal / Fixed M.
UNSPSC39121603
Upc785901425045
UPC785901878902
UPC Code785901878902
Voltage277
Voltage Rating277 V AC, 480 ; 480 ; 2.
Warranty DescriptionContractual Warranty:18.
Width0.98 in, 0.98, 0.98 mm
Width UOMInch
