Schneider Electric EDB14045

B00CONPOOI

SCHNEIDER ELECTRIC 277-VOLT 45-AMP EDB14045 Miniature Circuit Breaker 277V 45A

SCHNEIDER ELECTRIC 277-VOLT 45-AMP EDB14045 Miniature Circuit Breaker 277V 45Azoom

Attributes

Key Value
[Ue] Rated Operational .277 V AC
AC Voltage Rating277V AC
Ambient Air Temperature.40 ?C
Amperage Rating45, 45, 45 A
Amps45, 45 A
ApplicationNF panelboard;HACR rate.
Awg GaugeAWG 12...AWG 2/0 alumin.
AWG RangeAWG 12...AWG 2/0 alumin.
BrandSquare D by Schneider E.
Breaking Capacity18 kA 277 V AC || 18 kA.
Breaking Capacity CodeD
Catalog NumberEDB14045
China Rohs RegulationProduct out of China Ro.
Circuit Breaker ActuatorToggle
Circuit Breaker Applica.HACR rated || HID rated
Circuit Breaker Mountin.Bolt On
Circuit Breaker TypeStandard
Compatible Panelboard/L.NF
ConditionNew
ConnectionLugs aluminium;AWG 12...
Connection typeLug
Country of OriginMX - Mexico, Mexico
Country of Origin (subj.Mexico
Current Rating45A
DC Voltage RatingNot Rated
Depth4.05 in., 4.05 in
Device Short NameEDB
Dimensions4.05 in L x 0.98 in W x.
ECCNEAR99
Electrical Connectionlugs aluminium
Estimated Lead Time (in.5
Eu Rohs DirectiveCompliant
For Use WithSquare D NF Panelboards
FrameE-Frame, E
Frame Size125A/EDB
Frequency Rating50/60, 50/60 Hz
GTIN785901335139
Height5.66 in, 5.66 in., 5.66
Height UOMInch
Holding Current630 A
Interrupt Rating18 KA 277 V AC-18 KA 24.
ItemMiniature Circuit Break.
Item Typeminiature circuit-break.
Length5.66 in, 4.05
Length (Straight Wirewa.5.66 in
Length UOMInch
Line Rated Current45 A
Local Signallingtrip indicator
Made in USANo
ManufacturerSquare D, Schneider Ele.
MaterialThermoset Composite Res.
Max. AIR Rating18kA at 120/240V AC
Max. Operating Temp.104 Degrees F, 104 Degr.
Max. Wire Size2 AWG
Mercury FreeYes
Min. Wire Size12 AWG (Al), 14 AWG (Cu)
Module TypeE-Frame
MountingBolt On
Mounting ModeBolt-On
Mounting typeBolt-On
Mounting TypeBolt-On
Net Weight2 lb(US)
No. of Spaces1
Number of Poles1
Number Of Poles1
Number Of Spaces1
Number Of Spaces Requir.1
Operating Temperature40 A Degrees C
Phase1, Single, 1, 1 ph
Product CertificationscULus || IEC
Product DestinationNF panelboard
Product Or Component Ty.miniature circuit-break.
Product TypeMiniature Circuit Break.
Protection Typeoverload || short-circu.
Range Of Product125 A Frame EDB-EGB-EJB
Rated Voltage277V AC
Reach RegulationReference contains Subs.
Rohs Exemption Informat.Yes
SeriesEDB
Special Featurestrip indicator
StandardCULUS-IEC
StandardscULus, IEC
Sub BrandEDB
Temperature Rating (Deg.40, 40 deg C
Terminal ConnectionLug
Tightening Torque3.9-3.9 N.m 2.5-6 mm? (.
Torque3.9-3.9 N.m 2.5-6 mm? (.
Trip Range1800 AMPS, 1800 A, 630 .
Trip Typethermal-magnetic, Therm.
Trip Unit Rating1800-1800 A
Trip Unit Technologythermal-magnetic
TypeType EDB, Type EDB Mold.
UNSPSC39121603
UPC785901335139
Voltage Rating277, 277 VAC, 277 V AC
Warranty18 months
Warranty DescriptionContractual Warranty:18.
Weight2.000000
Width0.98 in, 0.98, 0.98 mm
Width UOMInch
Wire Size14 to 2/0 AWG, 12 to 2/.

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomindustrialrefrigerationparts.comEDB1404588.651In StockSquare D2.088.65 @ 1
simplybreakers.comEDB1404595.991In StockSchneider Electric95.99 @ 1
thumbzoomstandardelectricsupply.com2351885123.041In StockSquare D (Schneider Electric)123.04 @ 1
thumbzoomgordonelectricsupply.comEDB14045132.091In Stock10SQUARE D132.09 @ 1
thumbzoomZoroG2223094132.091In Stock70Square D132.09 @ 1
thumbzoommayerelectric.comSQDEDB14045145.141In StockSQUARE D2.0145.14 @ 1
thumbzoomcrescentelectric.com174647156.841In StockSquare D by Schneider Electric156.84 @ 1
Newark17C7573169.641In StockSQUARE D BY SCHNEIDER ELECTRIC169.64 @ 1
thumbzoomsustainablesupply.comC1180942172.221In StockSquare D1.04172.22 @ 1
Grainger2JWL3183.751In Stock18SQUARE D183.75 @ 1
Graybar97273054199.2481In StockSquare D (Schneider Electric)199.248 @ 1
thumbzoomRaptor SuppliesAF9HLC288.24277951In StockSQUARE D288.2427795 @ 1
grainger.caSQDEDB14045326.8897941In StockSQUARE D1.04326.889794 @ 1
