mpn:
brand:
manufacturer:
MPN:
Weight:
1.0
Weight:
0.06875 LB
Price:
202.51
qty:
21
simpleSku:
NDQ4OA:::QOU315VH
sku:
NDQ4OA::GC:QOU315VH@y0
condition:
11
seller:
superbreakers.com
amzMan:
square d
Dimensions:
[5.0, 4.0, 3.0]
Attributes
| Key | Value |
|---|---|
| AC Voltage Rating | 240V AC |
| Accessory / separate part type | None |
| Actuator Type | Toggle |
| Amperage | 15 |
| Amps | 15 A |
| Approval | UL, CSA, IEC |
| AWG gauge | AWG 14...AWG 2 (aluminium/copper) |
| Brand | Square D |
| Breaker Feature | Mercury Free |
| Category | 00900 - QOU BREAKERS & SWITCH |
| Circuit Breaker Actuator | Toggle |
| Circuit breaker application | HACR rated |
| Circuit Breaker Mounting Style | Surface/DIN Rail |
| Circuit breaker type | Standard |
| Circuit Breaker Type | High Interrupting Capacity, Standard |
| Commercial Status | Commercialised |
| Compatible Panelboard/Load Center Series | QO |
| Connection Type | Feed-Thru |
| Country of origin | MX |
| Country of Origin (subject to change) | Mexico |
| DC Voltage Rating | 48V DC |
| Depth | 2.95 in |
| Discount Schedule | DE2 |
| Electrical connection | Slotted box lugs (line and load) |
| For Use With | Air Conditioning and Refrigeration Equipment, Heating, Air Conditioning and Refrigeration Equipment, Heating, Panelboards and Load Centers |
| Frame Size | 100A/QOU |
| Frame Type | QOU |
| Functions | Long Time and Instantaneous Trip |
| GTIN | 00785901545705 |
| Interrupting Rating | 22kAIC at 240VAC |
| Item | Miniature Circuit Breaker |
| Length | 4.05 in |
| Length (Straight Wireway) | 4.05 in |
| Line Rated Current | 15 A |
| Max Wire Size | AWG 2 |
| Max. AIR Rating | 22kA at 240V AC |
| Max. Wire Size | 2 AWG |
| Min Wire Size | AWG 14 |
| Min. Wire Size | 14 AWG |
| Mounting | Unit mount |
| Mounting mode | Unit mount |
| Mounting Type | Unit, Surface, Din Rail |
| Nbr. of units in pkg. | 1 |
| Number of Poles | 3 |
| Phase | 3, Three |
| Poles | 3 |
| Poles description | 3P |
| Product availability | Non-Stock - Not normally stocked in distribution facility |
| Product certifications | IEC, CSA, UL listed |
| Product end of life instructions | Need no specific recycling operations |
| Product environmental profile | Available |
| Product or component type | Miniature circuit-breaker |
| Protection | Thermal Magnetic |
| Range of product | QOU |
| REACh | Reference not containing SVHC above the threshold |
| Returnability | N |
| RoHS (date code: YYWW) | Compliant - since 1323 -, Schneider Electric declaration of conformity |
| Series | QOU |
| Short-circuit current | 22 kA |
| Standards | RoHS, REACh, HACR, CSA, IEC, UL listed |
| Sustainable offer status | Green Premium product |
| System Voltage | 240 V AC |
| Temperature Rating | 40 ?C |
| Terminal Connection | Slotted Box Lug (Reversible Line and Load), Slotted Box Lug, Line and Load Side Lug |
| Voltage | 120/240VAC, 48VDC |
| Warranty period | 18 months |
| Width | 2.25 in |
| Wire Gauge | AWG 14 to AWG 2, Aluminum/Copper |
All Prices
| Img | Seller | Supplier SKU | Requested Price | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | superbreakers.com | QOU315VH | 202.51 | 202.51 | 1 | 1 | Square D | 202.51 @ Qty: 1+ | ||
 | mayerelectric.com | SQDQOU315VH | 375.42 | 375.42 | 1 | In Stock | SQUARE D | 375.42 @ Qty: 1+ | ||
 | Zoro | G0462034 | 399.44 | 399.44 | 1 | In Stock | 15 | Square D | 1.1 | 399.44 @ Qty: 1+ |
 | gordonelectricsupply.com | QOU315VH | 405.0 | 405.0 | 1 | In Stock | 10 | SQUARE D | 405.0 @ Qty: 1+ | |
| Grainger | 2JXL4 | 410.5 | 410.5 | 1 | In Stock | 21 | SQUARE D | 410.5 @ Qty: 1+ | ||
| us.rs-online.com | 72132200 | 440.44 | 440.44 | 1 | In Stock | Square D | 440.44 @ Qty: 1+ | |||
 | sustainablesupply.com | C1181085 | 475.73 | 475.73 | 1 | In Stock | Square D | 1.1 | 475.73 @ Qty: 1+ |
