CAI - SQUARE D QOU320VH

B07JVFZBCN

Square D Unit Mount Circuit Breaker, QOU, Number of Poles 3, 20 Amps, 240VAC, High Interrupting Capacity

Square D Unit Mount Circuit Breaker, QOU, Number of Poles 3, 20 Amps, 240VAC, High Interrupting Capacityzoom

Attributes

Key Value
AC Voltage Rating120/240V AC
Actuator TypeToggle
Amperage20
Amperage Rating20
Amps20 A
ApplicationHACR rated, HACR rated .
ApprovalIEC, UL, CSA
BrandSquare D, Square D by S.
Catalog NumberQOU320VH
Circuit Breaker ActuatorToggle
Circuit Breaker Mountin.Surface/DIN Rail
Circuit Breaker TypeHigh Interrupting Capac.
ConnectionAWG 14...AWG 2 aluminiu.
Connection TypeBolt-On
Country of OriginMexico
DC Voltage Rating48V DC
Depth2.95 in
For Use WithAir Conditioning and Re.
Frame Size100A/QOU
FunctionsLI - Long Time and Inst.
Gtin785901560012
Height4.05, 4.05 in
Height UOMInch
Interrupt Rating22KA
Interrupting Rating22kA at 240VAC
ItemMiniature Circuit Break.
Item TypeMiniature circuit-break.
Length2.95, 4.05 in
Length (Straight Wirewa.4.05 in
Length UOMInch
Made in USANo
ManufacturerSchneider Electric
Max Wire Size2 AWG
Max. AIR Rating22kA at 240V AC
Max. Wire Size2 AWG
Min Wire Size14 AWG
Min. Wire Size14 AWG
MountingUnit Mount
Mounting TypeUnit
MpnQOU320VH
Number of Poles3
Phase3, Three
Poles3
ProtectionThermal Magnetic
SeriesQOU
Special FeaturesSTANDARD FLUSH, SURFACE.
StandardUL489 LISTED - CSA 22.2.
StandardsCSA, IEC, UL listed, Ro.
Sub BrandQOU
Temperature Rating40?C
Terminal ConnectionLine and Load Side Lug,.
UPC785901560012
Voltage120/240VAC, 48VDC
Voltage Rating120/240 V AC
Warranty DescriptionContractual Warranty:18.
Width2.25, 2.25 in
Width UOMInch
Wire GaugeAWG 14 to AWG 2 Aluminu.

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomsuperbreakers.comQOU320VH220.91110Square D220.91 @ 1
thumbzoomZoroG1580101299.9912Square D1.11299.99 @ 1
Grainger2JXN1372.5120SQUARE D372.5 @ 1
standardelectricsupply.com2206604377.391In StockSquare D377.39 @ 1
thumbzoomgordonelectricsupply.comQOU320VH405.01In Stock10SQUARE D405.0 @ 1
thumbzoomRadwellQOU320VH420.01In StockSCHNEIDER ELECTRIC SQUARE D420.0 @ 1
thumbzoomsustainablesupply.comC1181089441.651In StockSquare D1.11441.65 @ 1
Newark33M9708459.171In StockSQUARE D BY SCHNEIDER ELECTRIC459.17 @ 1
us.rs-online.com72132205475.671In StockSquare D475.67 @ 1
steinerelectric.com966639507.211In StockSquare D?507.21 @ 1
thumbzoomcrescentelectric.com205421625.951In StockSquare D by Schneider Electric625.95 @ 1
thumbzoomRaptor SuppliesAF9HRP853.19728651In StockSQUARE D853.1972865 @ 1
