| [Ue] Rated Operational Voltage | 480Y/277 V AC |
| Ambient Air Temperature For Operation | 50 ?C |
| Awg Gauge | AWG 12...AWG 6 aluminium || AWG 14...AWG 6 copper |
| Breaking Capacity | 18 kA 277 V AC || 25 kA 240 V AC || 18 kA 480Y/277 V AC || 25 kA 120 V AC || 25 kA 120/240 V AC |
| Breaking Capacity Code | D |
| China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
| Circuit Breaker Application | HID rated || HACR rated |
| Depth | 4.05 in |
| Device Composition | shunt trip |
| Device Short Name | EDB |
| Electrical Connection | lugs aluminium |
| Eu Rohs Directive | Compliant |
| Height | 5.66 in |
| Holding Current | 270 A |
| Line Rated Current | 30 A |
| Local Signalling | trip indicator |
| Mercury Free, Rohs Exemption Information | Yes |
| Module Type | E-Frame |
| Mounting Mode | bolt-on |
| Net Weight | 4 lb(US) |
| Number Of Poles | 3 |
| Number Of Spaces, Number Of Spaces Required | 4 |
| Product Certifications | cULus |
| Product Destination | NF panelboard |
| Product Or Component Type | miniature circuit-breaker |
| Protection Type | overload || short-circuit |
| Range Of Product | 125 A Frame EDB-EGB-EJB |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| Tightening Torque | 3.4-3.4 N.m 2.5-16 mm? (AWG 14...AWG 6) |
| Trip Unit Rating | 875-875 A |
| Trip Unit Technology | thermal-magnetic |
| Warranty | 18 months |
| Width | 3.92 in |
