Square D QBL22090
Square Dzoom

Square D QBL22090

mpn:
QBL22090
brand:
SquareD
manufacturer:
SquareD
MPN:
QBL22090
Description:
SquareD QBL22090 MOLDED CASE CIRCUIT BREAKER 240V 90A CIRCUIT BREAKER 240V 90A - MROSupply.com
Weight:
45.0
Weight:
45.0 LB
Preferred Price:
389.4
Price:
389.4
Min Simple Price:
220.0
Absolute Min Price:
312.39
Min Price:
312.39
Dimensions:
[7.0, 4.0, 3.0]
qty:
21
simpleSku:
jMxNTk:::QBL22090
sku:
jMxNTk::HY:QBL22090@y0
condition:
11
seller:
gordonelectricsupply.com
amzMan:
square d
HazMat:
False
DropShip:
False

Attributes

Key ^Value
[Ue] Rated Operational Voltage240 V AC 50/60 Hz UL
[Uimp] Rated Impulse Withstand Voltage8 kV UL
Ambient Air Temperature For Operation40-70 ?C
Amperage Rating90
ApplicationPROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION
BrandSquare D by Schneider Electric
Breaking Capacity10 kA 120/208 V AC 50/60 Hz UL || 10 kA 240 V AC 50/60 Hz UL
Breaking Capacity Code, FrameB
California Proposition 65 : WARNING: This product can expose you to chemicals includingDINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Catalog NumberQBL22090
China Rohs RegulationProduct out of China RoHS scope. Substance declaration for your information.
Circuit Breaker ApplicationHACR rated
ConnectionLUGS LOAD AWG 4...300 KCMIL ALUMINIUM/COPPER-LUGS LINE AWG 4...300 KCMIL ALUMINIUM/COPPER
Continuous Current Rating80 %
Control Typeoperating handle
Country of OriginMexico
Depth, Length3.93 in
Device Applicationdistribution
Electrical Connectionlugs, load || lugs, line
Environmental DisclosureENVPEP1406032EN
Eu Rohs DirectiveCompliant
Halogen Content PerformanceHalogen free product
Height6.47, 6.47 in
Height UOM, Width UOMInch
Interrupt Rating10 KA 240 V AC,240 V AC
Item Type, Product Or Component Typecircuit breaker
Line Rated Current90-90 A, 90 A
Local Signalling1 trip indicator green)
Made in USANo
Magnetic Hold Current1000 A
Magnetic Tripping Current1800-1800 A
ManufacturerSchneider Electric
Mechanical Durability1000 cycles loaded || 5000 cycles no load
Mercury Free, Pvc Free, Reach Free Of Svhc, Rohs Exemption InformationYes
Mounting Modeunit mount lug)
Mounting Supportlug
Network Frequency50/60 Hz
Number of Poles2
Poles Description2P
Product CertificationsUL || CSA || NOM
Product NamePowerPact Q
Range, Sub BrandPowerPact
Special FeaturesUNIT MOUNT
StandardIEC-CSA-UL LISTED
StandardsUL || CSA || NEMA || NOM-003-SCFI-2000
Sustainable Offer StatusGreen Premium product
Tightening Torque28-28 N.m 25-150 mm? (AWG 4...300 kcmil)
Trip Range1000 A,1800 A,90 A
Trip Type, Trip Unit Technologythermal-magnetic
UPC785901407584
Utilisation Categorycategory A
Voltage Rating240 V AC
Warranty18 months
Warranty DescriptionContractual Warranty:18 months
Width3.00 in, 3.0
Wire Stripping Length22 mm

All Prices

ImgSellerSupplier SKURequested Price ^Calc MOQ PriceMOQIn StockLead TimeBrandWeightPreferred Tier
thumbzoomgordonelectricsupply.comQBL22090220.0220.01In Stock10SQUARE D220.0 @ Qty: 1+
thumbzoomRadwellQBL22090290.0290.01In StockSCHNEIDER ELECTRIC SQUARE D290.0 @ Qty: 1+
thumbzoommayerelectric.comSQDQBL22090323.92323.921In StockSQUARE D323.92 @ Qty: 1+
simplybreakers.comQBL22090335.99335.991In StockSchneider Electric335.99 @ Qty: 1+
thumbzoomRaptor SuppliesAG8TXB589.201002589.2010021In StockSQUARE D589.201002 @ Qty: 1+
Newark89H5582832.21832.211In StockSQUARE D BY SCHNEIDER ELECTRIC832.21 @ Qty: 1+
thumbzoomcrescentelectric.com2863801021.371021.371In StockSquare D by Schneider Electric1021.37 @ Qty: 1+
