| Applications, Contact Length - Mating, Contact Length - Post, Ingress Protection, Overall Contact Length, Voltage Rating | - |
| Base Product Number, Series | SBH11 |
| Category | Connectors, Interconnects |
| Connector Type | Header |
| Contact Finish - Mating, Contact Finish - Post | Gold |
| Contact Finish Thickness - Mating, Contact Finish Thickness - Post | Flash |
| Contact Material | Brass |
| Contact Shape | Square |
| Contact Type | Male Pin |
| Current Rating (Amps) | 3A |
| Fastening Type | Push-Pull |
| Features | Keying Slot |
| Insulation Color | Black |
| Insulation Height | 0.358" (9.10mm) |
| Insulation Material | Polyamide (PA), Nylon |
| Mated Stacking Heights | 11.17mm, 12.72mm, 14.87mm, 19.87mm |
| Material Flammability Rating | UL94 V-0 |
| Mfr | Sullins Connector Solutions |
| Mounting Type | Surface Mount |
| Number of Positions | 16 |
| Number of Positions Loaded | All |
| Number of Rows | 2 |
| Operating Temperature | -40?C ~ 105?C |
| Package | Tube |
| Pitch - Mating, Row Spacing - Mating | 0.100" (2.54mm) |
| Product Status | Active |
| Shrouding | Shrouded - 4 Wall |
| Style | Board to Board or Cable |
| Termination | Solder |
