| ANSI Code | NU-CNMA430.5 |
| ANSI Number | NUCNMA430.5-BN2000 |
| Cast Iron (K) Compatibility, Hardened (H) Compatibility, Steel (P) Compatibility, Super Alloy (S) Compatibility | Yes |
| Chip-Breaker, Non Ferrous (N) Compatibility, Stainless (M) Compatibility | No |
| Clearance Angle | 0 Degrees |
| Coating | CVD |
| Corner Radius | 0.0079 in |
| Country of Origin (subject to change) | Multiple |
| Cutting Application | Turning |
| Cutting Direction | Neutral |
| Depth of Cut | 0.0150 in |
| Features | Excellent Wear Resistance and Fracture Resistance |
| Finish - Machining | Bright (Uncoated) |
| For Use With | Toolholders, Boring Bars |
| Grade, Manufacturer Grade | BN2000 |
| Included Angle | 80 Degrees |
| Inscribed Circle | 1/2 in |
| Insert Application | Finishing |
| Insert Holding Type | Straight Hole |
| Insert Material, Material, Material - Machining | CBN |
| Insert Shape | Diamond |
| Insert Size | 430.5 |
| Insert Style | CNMA |
| Insert Thickness | 0.1875" |
| ISO Number | NU-CNMA120402 |
| Item | Diamond Turning Insert |
| Measurement System | Fractional Inch |
| Mounting Hole Dia. | 0.203" |
| Mounting Style | Top and Hole Clamping |
| No. of Edges, Number of Cutting Edges | 1 |
| Nose Radius | 0.0078" |
| Primary Material Application | Hardened Steel |
| Primary Material Application ISO Code | H10 - H20 |
| Rake | Negative |
| Shape | Rhombic |
| Thickness | 3/16 in |
| Workpiece Compatibility | Cast Iron (K), Hardened (H), Steel (P), Super Alloy (S) |
