mpn:
brand:
manufacturer:
MPN:
Description:
(One)? Brand New Genuine Switchcraft AAA3FZ 3 Pin XLR Female Connector ?(Made in America) ? Only two pieces to assemble ? Easy twist on handle reduces assembly time ? Rugged die-cast metal handle ? Strain relief accommodates wide cable OD ranges ? Nickel?finish ????????? Ideal for consumer electronics, broadcast studio
Weight:
0.02
Weight:
0.004 LB
Preferred Price:
5.26
Price:
5.26
Min Simple Price:
2.13
Absolute Min Price:
4.11
Min Price:
4.11
Dimensions:
[6.0, 4.0, 2.0]
qty:
32
simpleSku:
zIzOTE:::AAA3FZ
sku:
zIzOTE::47:AAA3FZ@y0
condition:
11
seller:
Adorama
amzMan:
switchcraft/conxall
HazMat:
False
DropShip:
False
Attributes
| Key ^ | Value |
|---|---|
| Angle | Straight |
| Applications | Audio, Industrial, Instrumentation, Medical |
| Backshell Material, Plating | Zinc Alloy, Nickel |
| Base Product Number, Contact Finish Thickness - Mating, Ingress Protection, Material Flammability Rating, Mounting Feature, Operating Temperature, Shell Size, MIL | - |
| Body Material | Zinc |
| Cable Opening | 0.100" ~ 0.220" (2.54mm ~ 5.59mm) |
| Category | Connectors, Interconnects |
| Color, Contact Finish - Mating, Contact Plating | Silver |
| Connector Type | Plug, Plug, Female Sockets |
| Contact Material | Copper Alloy |
| Current Rating | 15 A |
| Current Rating (Amps) | 15A |
| Description | CONN PLUG FMALE XLR 3POS SOLDER |
| Detailed Description | 3 Position Circular Connector Plug, Female Sockets Solder Cup |
| Digi-Key Part Number | SC2428-ND |
| Fastening Type | Latch Lock |
| Features | Backshell, Cable Clamp, Ground, Strain Relief |
| Housing Material | Rugged Die-Cast Metal |
| Insert Material | Thermoplastic |
| Insulation Type | Insulated |
| Manufacturer Part Number, Manufacturer Product Number | AAA3FZ |
| Manufacturer Standard Lead Time | 12 Weeks |
| Manufacturer, Mfr | Switchcraft Inc. |
| Mounting Type | Free Hanging (In-Line), Cable |
| Number of Contacts, Number of Positions | 3 |
| Orientation | Keyed |
| Package, Packaging | Bulk |
| Primary Material | Metal |
| Primary Type, Shell Size - Insert | XLR |
| Product Header | AAA Series Q-G? Twist XLR Connector |
| Product Status | Active |
| RoHS Status | ROHS3 Compliant |
| Series | AAA Series, Q-G, Q-G? AAA |
| Shell Finish | Nickel |
| Shell Material | Zinc Alloy |
| Shielding | Shielded |
| Standard Package | 100 |
| Termination | Solder Cup |
| Type | Jack |
| Voltage Rating | 125VAC, 125 V |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| Adorama | SWAAA3FZ | 2.13 | 2.13 | 1 | 46 | Switchcraft | 2.13 @ Qty: 1+ | |||
| MCM Electronics | 101-278 | 2.59 | 2.59 | 1 | 46 | Switchcraft/Conxall | 2.59 @ Qty: 1+ | |||
| Hawk Electronics | AAA3FZ | 3.06 | 124.236 | 100 | 32 | Switchcraft | 3.06 @ Qty: 100+ | |||
 | iodParts | AAA3FZ | 3.303 | 134.1018 | 100 | 300 | Switchcraft | 3.303 @ Qty: 100+ | ||
 | Markertek | AAA3FZ | 3.4 | 3.4 | 1 | 32 | Switchcraft | 3.4 @ Qty: 1+ | ||
 | Full Compass | AAA3FZ | 3.49 | 3.49 | 1 | 32 | SWITCHCRAFT | 3.49 @ Qty: 1+ | ||
| Electroshield | AAA3FZ | 4.09 | 166.054 | 100 | 32 | SWITCHCRAFT | 4.09 @ Qty: 1+ | |||
 | Newark | 14R8563 | 4.22 | 4.22 | 1 | 158 | SWITCHCRAFT/CONXALL | 4.22 @ Qty: 1+ | ||
| Onlinecomponents.com | AAA3FZ | 4.411 | 20.2906 | 10 | 368 | Switchcraft | 4.411 @ Qty: 10+ | |||
 | Digi-Key | 1288944 | 5.73 | 5.73 | 1 | 692 | Switchcraft Inc. | 5.73 @ Qty: 1+ | ||
| us.rs-online.com | 70214580 | 5.97 | 242.382 | 100 | 32 | Switchcraft | 5.97 @ Qty: 100+ | |||
 | usbargainsound.com | D8F583CF466D468BB49F72492B76B27A | 7.59 | 7.59 | 1 | 32 | Switchcraft | 7.59 @ Qty: 1+ | ||
| RS Delivers | 362-1098 | 13.572 | 13.572 | 1 | 58 | Switchcraft | 13.572 @ Qty: 1+ | |||
| AmazonSC | B011NO0WC2 | 33.58 | 33.58 | 1 | 32 | Switchcraft | 33.58 @ Qty: 1+ |
