TB Woods 14SC78

mpn14SC78
brandname: T.B. Woods
manufacturername: T.B. Woods

Tb Woods 14SC78 Coupling

Tb Woods 14SC78 Coupling

zoom

Brand: TB Woods
PartNumber: 14SC78
PackageQuantity: 1
Binding: Misc.
Manufacturer: TB Woods
Label: TB Woods

Attributes

Key	Value
Component WR2 (lbs ft2)	9.0261
Component WR?	9.0261
Coupling size	14
Dimension (in) (D)	13.875
Dimension (in) (H)	6-1/2
Dimension (in) (L)	2 23/32
Dimension (in) (T)	2 1/4
Dimension (in.) (E)	1/32
Distance betewwn shaft .	7 3/4
Distance between shaft	7.75
Flange diameter	13.875
Horsepower Rating at 10.	69
Length	69
Length through bore	2.71875
Material type	High strength cast iron
Max angular gap misalig.	0.242 (in) with EPDM/Ne.
Max angular misalignment	1? with EPDM/neoprene s.
Max compatible bore size	5
Max parallel misalignme.	In Stock
Max RPM	2200
Max speed	2200
Min compatible bore size	1
Outside diameter	13.875
Power rating at 100 RPM	86 kW with EPDM or Neop.
Screw type	Flange, Spacer
SF flange length	2.25
SF hub diameter	6.5
SF hub length	1/32
Spacer hub required	14SCH x Bore Spacer Hub
Torque	23,400 in-lb with EPDM .
Torque rate	23,400 (in-lbs) with EP.

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	MRO Supply	338606	543.8	1	In Stock		TB Woods		543.8 @ 1
	us.rs-online.com	73973604	745.38	1	In Stock		TB Wood's (Altra)		745.38 @ 1
