TB Woods 8MPC224S62

mpn8MPC224S62
brandname: T.B. Woods
manufacturername: T.B. Woods

TB Woods 8MPC-224S-62-3525 QTPCII SPK (8MPC224S62)

TB Woods 8MPC-224S-62-3525 QTPCII SPK (8MPC224S62)

zoom

Brand: TB Woods
PartNumber: 8MPC224S62
PackageQuantity: 1
Manufacturer: TB Woods
Label: TB Woods

Attributes

Key	Value
Belt width	62 mm
Bore type	Taper locking bushing
Bushing	3525
Bushing bore range	1 3/16 - 3 15/16
Dimension	2.5
Face width	2.91
Flanges	0
Groove profile	8M
Hub Diameter	8.75
Hub diameter	8.75
Hub length	2.5
Hub location	0.41
I.D.	19.69
Inertia WR2 (lbs ft2)	64.6
Inertia WR?	829
Inside hub projection	0
Material type	Cast iron
Number of grooves	224
Number of hubs	2
Number of teeth	224
O.D.	22.39
O.D. (in)	22.394
Outside hub projection	0
Pitch	8
Pitch diameter	22.46
Rim face	2.91
RPM upper limit	1120
Tooth pitch	8
Type	A3

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	MRO Supply	836431	928.28	1	In Stock		TB Woods		928.28 @ 1
