TE Raychem JMSWD-5XL

B07NQTR51J

TE Raychem Connector

TE Raychem Connectorzoom

Attributes

Key Value
Base Product NumberJMSWD
CategoryRelays
Coil Resistance100 Ohms, 100 ?
Coil TypeNon Latching, Non-Polar.
Coil Voltage5VDC
Coil Volts5V DC
Contact FormDPDT (2 Form C)
Contact Form - Relay2 Form C, DPDT, 2 C/O
Contact MaterialSilver Palladium (AgPd).
Contact Rating1A
Contact Rating (Current)1 A
DescriptionJMSWD-5XL = M39016/16-0.
Detailed DescriptionGeneral Purpose Relay D.
Digi-Key Part NumberJMSWD-5XL-ND
Electrical Connection -.Long Leads
FeaturesDiode, Coil Suppression.
Item - RelayMilitary/Aerospace High.
ManufacturerTE Connectivity Aerospa.
Manufacturer Product Nu.JMSWD-5XL
Manufacturer Standard L.21 Weeks
MfrTE Connectivity Aerospa.
Mounting TypePrinted Circuit Board, .
Must Operate Voltage2.6 VDC
Must Release Voltage0.23 VDC
Operate Time4 ms
Operating Temp. Range-65 to 125?C
Operating Temperature-65?C ~ 125?C
PackageBulk
Package Quantity1
Power Consumption - Rel.250 mW
Product StatusActive
Relay TypeGeneral Purpose
Release Time7.5 ms
Seal RatingSealed - Hermetically
SeriesMilitary, MIL-R-39016/1.
Switching Voltage115VAC, 28VDC - Max
Termination StylePC Pin

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
VericalJMSWD-5XL42.36727TE Connectivity / CII42.367 @ 2
thumbzoomComponent Electronics723-14457.6912Tyco Electronics57.69 @ 1
WaldomTE CONNECTIVITY AMP BRAND 1617132-697.8415TE CONNECTIVITY/AMP BRAND97.84 @ 1
Allied ElectronicsE5192633109.7510In StockTE Connectivity109.75 @ 10
Mouser655-JMSWD-5XL118.791In StockTE Connectivity / CII118.79 @ 1
thumbzoomDigi-Key6064896142.4215TE Connectivity Aerospace, Defense and Marine142.42 @ 1
thumbzoomZoroG705866205249.991In StockTe Connectivity249.99 @ 1
