Generic T9AP1D22-18-01

B07QFQ3GSP

T9AP1D22-18-01, Relay,E-Mech,SPST-NO,Ctrl-V 18DC,30A,277VAC,PCB MNT,Thru-Hole/QC Term,T9A Series

T9AP1D22-18-01, Relay,E-Mech,SPST-NO,Ctrl-V 18DC,30A,277VAC,PCB MNT,Thru-Hole/QC Term,T9A Serieszoom

Attributes

Key Value
Alternate Mfr Part Numb.1-1419104-1
Base Product NumberT9AP1
CategoryRelays
Coil Current55.6 mA
Coil InsulationClass F
Coil Resistance324 Ohms
Coil TypeNon Latching
Coil Voltage18VDC
Contact FormSPST-NO (1 Form A), SPS.
Contact MaterialSilver Cadmium Oxide (A.
Contact Rating (Current)30 A
Contact Voltage Rating300
DescriptionRELAY GEN PURPOSE SPST .
Detailed DescriptionGeneral Purpose Relay S.
Digi-Key Part NumberPB1948-ND
Features-
FunctionGeneral Purpose
ManufacturerTE Connectivity Potter .
Manufacturer Product Nu.T9AP1D22-18-01
Manufacturer Standard L.22 Weeks
MfrTE Connectivity Potter .
Mounting TypeThrough Hole
Must Operate Voltage13.5 VDC
Must Release Voltage1.8 VDC
Operate Time15 ms
Operating Temperature-55?C ~ 85?C
PackageBulk
Primary TypePower Relays
Product StatusActive
Relay TypeElectromechanical, Gene.
Release Time15 ms
Seal Rating-
SeriesT9A, T9A Series
StandardsUL ; CSA
Switching Voltage277VAC - Max
Termination StylePC Pin, Quick Connect -.

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Newark08H51913.810002POTTER&BRUMFIELD - TE CONNECTIVITY3.8 @ 1000
Onlinecomponents.comT9AP1D22-18-013.861997TE Connectivity / P&B Brand3.86 @ 2
thumbzoomDigi-Key14277254.95465610002TE Connectivity Potter & Brumfield Relays4.954656 @ 1000
Mouser655-T9AP1D22-18-016.11772TE Connectivity6.1 @ 2
us.rs-online.com701993287.0812TE Connectivity7.08 @ 2
VericalT9AP1D22-18-017.868410TE Connectivity7.86 @ 8
