Attributes
| Key ^ | Value |
|---|---|
| Alternate Part No. | 655-KHAU-17A12-12 |
| Base Product Number | KHAU |
| Body Depth - Relay | 1.111 in |
| Body Height - Relay | 1.261 in |
| Body Width - Relay | 0.858 in |
| Brand | TE Connectivity / P&B |
| Category | Relays |
| Coil Current | 100 mA |
| Coil Insulation | Class B |
| Coil Resistance | 43 Ohms, 43 ? |
| Coil Termination, Termination Style | Solder Lug |
| Coil Type | Non-Latching, Non Latching, Monostable, AC |
| Coil Voltage | 12VAC, 12 VDC |
| Coil Volts | 12V AC |
| Contact Current Rating, Contact Rating (Current), Maximum Switching Current | 5 A |
| Contact Form | 4PDT (4 Form C) |
| Contact Form - Relay | 4 Form C (CO) |
| Contact Limiting Breaking Current, Contact Limiting Continuous Current, Contact Limiting Making Current, Contact Limiting Short-Time Current | 5A |
| Contact Material | AgCdO, Silver Cadmium Oxide, Silver Cadmium Oxide (AgCdO) |
| Contact Rating | 0.208333333333333A |
| Contact Termination | Solder |
| Contact Voltage Rating, Switching Voltage | 240 VAC |
| Dielectric Voltage | 1500 Vrms Adjacent Contacts; 1500 Vrms, 1500 V Coil and Contact; 1000 Vrms Open Contacts |
| Features | UL Coil Insulation Class B |
| Features, Must Release Voltage, Seal Rating | - |
| Height | 32.5 mm |
| Item - Relay | Industrial Panel Plug-In Power Relay |
| Length | 28.2 mm |
| Manufacturer | TE Connectivity |
| Manufacturer Part No. | KHAU-17A12-12 |
| Mfr | TE Connectivity Potter & Brumfield Relays |
| Mounting Style, Mounting Type | Socket |
| Mounting Type | Socketable, DIN Rail |
| Must Operate Voltage | 10.2 VAC |
| Number of Poles | 4 |
| Operate Time | 13 ms |
| Operating Temp. Range | -45 to 70?C |
| Operating Temperature | -45?C ~ 70?C |
| Package | Bulk |
| Part # Aliases | 2-1393122-7 |
| Power Consumption | 1.2 VA |
| Power Consumption - Relay | 1.2VA |
| Product | Power Relays |
| Product Category | General Purpose Relays |
| Product Status | Active |
| Protection Category | RTI |
| Relay Type | General Purpose |
| Release Time | 6 ms |
| Series | KHA |
| Switching Current | 300mA @ 12V |
| Switching Voltage | 240VAC - Max |
| Terminal Type | Plug-In, Solder |
| Termination Style | Plug In |
| Type | Standard |
| Width | 21.8 mm |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| Waldom | TE CONNECTIVITY POTTER-BRUMFIELD KHAU-17A12-12 | 34.78 | 48.692 | 2 | 98 | TE CONNECTIVITY / POTTER-BRUMFIELD | 34.78 @ Qty: 2+ | |||
| Newark | 51B963 | 39.12 | 5500.272 | 350 | In Stock | POTTER&BRUMFIELD - TE CONNECTIVITY | 39.12 @ Qty: 350+ | |||
| Digi-Key | 1128218 | 39.74754 | 5588.504124 | 350 | In Stock | TE Connectivity Potter & Brumfield Relays | 39.74754 @ Qty: 350+ | |||
| Onlinecomponents.com | KHAU-17A12-12 | 40.43 | 40.43 | 1 | 83 | TE Connectivity / P&B Brand | 40.43 @ Qty: 1+ | |||
| us.rs-online.com | 71996652 | 45.52 | 6400.112 | 350 | In Stock | TE Connectivity | 45.52 @ Qty: 350+ | |||
 | swatee.com | KHAU-17A12-12 | 48.73 | 48.73 | 1 | 20 | TE Connectivity | 48.73 @ Qty: 1+ | ||
| AmazonSC | B00HKIA5KK | 51.25 | 51.25 | 1 | In Stock | TE Connectivity | 51.25 @ Qty: 1+ | |||
| Amazon | B00FRBQZME | 55.48 | 55.48 | 1 | In Stock | TE Connectivity / AMP | 55.48 @ Qty: 1+ | |||
 | Zoro | G005866042 | 95.3 | 95.3 | 1 | In Stock | Te Connectivity | 95.3 @ Qty: 1+ |
