Alternate Mfr Part Number | 1-2157480-3 |
Angle | Straight |
Blindmate, NASA Qualification, Non-Magnetic, Power/Signal/Coax Combination, Preloaded, ULTRA-LITE Connector | No |
Box Mount D-Sub Connector Insert Arrangement | MS18275-1 |
Category | Connectors, Interconnects |
Centerline (Pitch) | 2.77?mm?[?.109?in?] |
Circuit Application, Shell Size, Connector Layout | Signal |
Color | Contacts Not Included |
Connector | Wire & Cable |
Connector Style | Plug, Plug for Male Contacts |
Connector System | Cable-to-Cable |
Connector Type, Number of Contacts, Number of Positions | 25 |
Contact Base Material | Copper Alloy |
Contact Current Rating (Max) | 7.5 |
Contact Mating Area Plating Material | Gold over Nickel |
Contact Mating Area Plating Thickness | 1.3??m?[?50 ? 100??in?] |
Contact Size | 20 |
Contact Style, Contact Type | Pin |
Contact Type | Free Hanging (In-Line) |
Country of Origin (subject to change) | United States |
Dielectric Material, Flange Feature, Operating Temperature, Shell Material, Finish | - |
Features | Steel, Cadmium Plated |
Front Shell Material, Rear Shell Material, Shell Material | Steel |
Front Shell Plating Finish, Shell Plating Finish | Yellow Chromate |
Front Shell Plating Material, Housing Finish, Rear Shell Plating Material, Shell Plating Material | Cadmium |
Ingress Protection | -50?C ~ 125?C |
Mating Cycles | Polyester, Glass Filled |
Mfr | TE Connectivity Aerospace, Defense and Marine |
Mounting Type | Housing/Shell (Unthreaded) |
Note, Number of Rows | 2 |
Number of Positions | 3 (DB, B) |
Operating Temperature Range | -55 ? 125??C?[?-67 ? 257??F?] |
Package | Active |
Packaging Method | Individual |
Part Status, Primary Type | D-Sub |
Product Type | Connector |
Retention Clip Material | Stainless Steel |
Sealable | Yes |
Series | Bulk, Amplimite 109 Series |
Shell Finish Thickness | IP67 - Dust Tight, Waterproof |
Shell Size | 3 |
Termination | Crimp |
Type | Cable Plug |
