| Base Product Number | CSD18540 |
| Category | Discrete Semiconductor Products |
| Current - Continuous Drain (Id) @ 25?C | 100A (Ta) |
| Drain to Source Voltage (Vdss) | 60 V |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| FET Feature | - |
| FET Type | N-Channel |
| Gate Charge (Qg) (Max) @ Vgs | 53 nC @ 10 V |
| Input Capacitance (Ciss) (Max) @ Vds | 4230 pF @ 30 V |
| Mfr | Texas Instruments |
| Mounting Type | Surface Mount |
| Operating Temperature | -55?C ~ 150?C (TJ) |
| Package | Tape & Reel (TR) |
| Package / Case | 8-PowerTDFN |
| Power Dissipation (Max) | 3.1W (Ta), 195W (Tc) |
| Product Status | Active |
| Rds On (Max) @ Id, Vgs | 2.2mOhm @ 28A, 10V |
| Series | NexFET? |
| Supplier Device Package | 8-VSON-CLIP (5x6) |
| Technology | MOSFET (Metal Oxide) |
| Vgs (Max) | ?20V |
| Vgs(th) (Max) @ Id | 2.3V @ 250?A |
