Texas Instruments SN74HC00NSR

B00AVSH8Y2

SN74HC00NSR

SN74HC00NSRzoom

Attributes

Key Value
Alternate Part No.595-SN74HC00NSR
Base Product Number74HC00
BrandTexas Instruments
CategoryIntegrated Circuits (IC.
Current - Output High, .5.2mA, 5.2mA
Current - Quiescent (Ma.2 ?A
Features-
High Level Output Curre.- 5.2 mA
Logic FamilyHC
Logic Level - High1.5V ~ 4.2V
Logic Level - Low0.5V ~ 1.8V
Logic TypeNAND Gate
Low Level Output Current5.2 mA
ManufacturerTexas Instruments
Manufacturer Part No.SN74HC00NSR
Max Propagation Delay @.15ns @ 6V, 50pF
Maximum Operating Tempe.+ 85 C
MfrTexas Instruments
Minimum Operating Tempe.- 40 C
Mounting StyleSMD/SMT
Mounting TypeSurface Mount
Number of Circuits4
Number of Gates4 Gate
Number of Input Lines2
Number of Inputs2
Number of Lines In/Out2 / 1
Number of Output Lines1
Operating Temperature-40?C ~ 85?C
Operating Temperature R.- 40 C to + 85 C
PackageTape & Reel (TR)
Package / Case14-SOIC (0.209", 5.30mm.
Package/CaseSOP-14
PackagingReel
ProductNAND
Product CategoryLogic Gates
Product StatusActive
Propagation Delay Time23 ns
SeriesSN74HC00, 74HC
Supplier Device Package14-SO
Supply Voltage - Max6 V
Supply Voltage - Min2 V
Unit Weight208.300 mg
Voltage - Supply2V ~ 6V

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
HotendaH25434580.141051708Texas Instruments0.14105 @ 1
thumbzoomNewark86W61670.1644000609TEXAS INSTRUMENTS0.164 @ 4000
Win SourceSN74HC00NSR0.31008174Texas Instruments0.3 @ 100
ArrowSN74HC00NSR0.3152000609Texas Instruments0.315 @ 2000
Mouser595-SN74HC00NSR0.461609Texas Instruments0.46 @ 1
thumbzoomswatee.comSN74HC00NSR0.651836Texas Instruments0.65 @ 1
Digi-Key74943312.861609Texas Instruments12.86 @ 1
