Vishay VS-VSKD166/16PBF

B008RDA598

Vishay Diode, Standard, 165A, 1600V - VS-VSKD166/16PBF

Vishay Diode, Standard, 165A, 1600V - VS-VSKD166/16PBFzoom

Attributes

Key Value
Alternate Part No.844-VSKD166/16PBF
ApprovalsUL
Base Product NumberVSKD166
BrandVishay Semiconductors
Breakover Current IBO M.4200 A
CaseINT-A-Pak
CategoryDiscrete Semiconductor .
CircuitDiode Doubler
Circuit TypeDiodes
Current - Average Recti.82.5A
Current - Reverse Leaka.20 mA @ 1400 V
Current Rating165 A
Diode Configuration1 Pair Common Cathode
Diode TypeStandard
Electrical mountingscrew
Family SeriesVishay Power Modules, V.
Gross Weight0.4438 lbs
It (avg)165 A
It (rms)260 A
Item NumberVSKD166/16PBF
Load current165A
ManufacturerVISHAY
Manufacturer Part No.VS-VSKD166/16PBF
Manufacturer Part NumberVS-VSKD166/16PBF
Max. forward impulse cu.5.5kA
Max. forward voltage1.46V
Max. off-state voltage1.6kV
Maximum Operating Tempe.+ 150 C
Mechanical mountingscrew
MfrVishay General Semicond.
Minimum Operating Tempe.- 40 C
Mounting Centers80 mm
Mounting StyleChassis
Mounting TypeChassis Mount
Net Weight0.4438 lbs
Nominal Depth (mm)35 mm
Nominal Height (mm)37 mm
Nominal Width (mm)94 mm
Non Repetitive On-State.4000 A
Off-State Leakage Curre.20 mA
On-State RMS Current - .260 A
On-State Voltage1.43 V
Operating Temperature -.-40?C ~ 150?C
PackageBulk
Package / CaseINT-A-Pak
Package TypeINT-A-Pak
Package/CaseINT-A-Pak
PackagingBulk
Part StatusActive
Product CategorySCR Modules
Product SeriesVSK166
Rated Repetitive Off-St.1.6 kV
RoHSYes
Semiconductor structuredouble series
SeriesVS-VSK.166..PbF, VS-VSK.
SpeedStandard Recovery >500n.
Supplier Device PackageINT-A-Pak
Type of modulediode
Voltage - DC Reverse (V.1600 V
Vrrm1,600 V

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomGalcoVSKD166/16PBF-VISH56.6215In StockVishay0.443856.62 @ 15
thumbzoomNewark97K231266.161In StockVISHAY66.16 @ 1
Digi-Key493294667.3310In StockVishay General Semiconductor - Diodes Division67.33 @ 1
RS Delivers395-800381.6616Vishay81.66 @ 1
TMEVS-VSKD166/16PBF97.951In StockVISHAY97.95 @ 1
thumbzoomswatee.comVS-VSKD166/16PBF154.7113Vishay154.7 @ 1
