Walter Tools M22213-UNC5

mpnM22213-UNC5
brandname: Walter Prototyp
manufacturername: Walter Prototyp

Walter Tools M22213-UNC5 Prototex HSS Machine Tap, VAP Finish, 3.5 mm Shank Diameter, 10 mm Cutting Length, 56 mm Overall Length, No. 5-40 Cutting Diameter

Walter Tools M22213-UNC5 Prototex HSS Machine Tap, VAP Finish, 3.5 mm Shank Diameter, 10 mm Cutting Length, 56 mm Overall Length, No. 5-40 Cutting Diameter

zoom

Brand: Walter Tools
PartNumber: M22213-UNC5
Model: 6149906
Size: No. 5-40
PackageQuantity: 1
Binding: Misc.
Manufacturer: Walter
Label: Walter

Attributes

Key	Value
55% Thread Drill Size	#36
65% Thread Drill Size	#37
75% Thread Drill Size	#39
Class of Fit	H3
Coolant Fed	Non-Coolant Through
Country of Origin (subj.	Germany
Cutting Direction - Mac.	Right Hand
Drill Bit Size	0.1040 in
Extended Neck	Yes
Helix Angle	0 Degrees
Item	Spiral Point Tap
List Number	M22213
Measurement System	Pipe
Number of Flutes	2
Number of Pieces	1
Overall Length	2-1/4"
Pitch Diameter Limit	2B
Primary Material Applic.	Stainless Steel
Primary Material Applic.	M
Secondary Material Appl.	Steel
Secondary Material Appl.	P
Series	Prototex X?pert M
Shank Dia.	1/8"
Shank Length	38.00 mm
Shank Type - Machining	Straight
Spiral Direction	Neutral
Square Size	2.70 mm
Tap Chamfer	Taper
Tap Dimension Type	Inch
Tap Finish	Steam Oxide
Tap Material	High Speed Steel
Tap Size	#5
Tap Style	Spiral Point
Tap Thread Size	#5-40
Tap Thread Type	UNC
Thread Direction	Right Hand
Thread Length	3/8"
Thread Limit	H2, H3
Thread Limit / Class of.	H2 / H3, H3 / H3
Thread Size	#5-40
Thread Standard	UNC
Threads per Inch	40

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	Zoro	G2518061	37.39	1	In Stock		Walter Prototyp	0.01	37.39 @ 1
