mpn:
brand:
manufacturer:
MPN:
Weight:
1.0
Weight:
1.0 LB
Preferred Price:
351.57
Price:
351.57
Min Simple Price:
198.63
Absolute Min Price:
282.05
Min Price:
282.05
Dimensions:
[5.0, 1.0, 1.0]
qty:
21
simpleSku:
zY2MzE:::A3289DPL-13/32IN
sku:
zY2MzE::CK:A3289DPL-13/32IN@y0
condition:
11
seller:
Zoro
amzMan:
walter
HazMat:
False
DropShip:
False
Attributes
| Key ^ | Value |
|---|---|
| Application | For Steel, Stainless Steel, Cast Iron, Non-Ferrous Metals, High-Temperature Alloys, Titanium Alloys and Hard Materials |
| Coolant Fed | Coolant Through |
| Coolant Through | Yes |
| Country of Origin (subject to change) | Germany |
| Cutting Direction | Right Hand |
| Decimal Equivalent | 0.4063 |
| Depth x Dia. Ratio, Depth:Dia. Ratio | 3xD |
| Drill Bit Dimension Type, Measurement System | Fractional Inch |
| Drill Bit Finish, Finish - Machining | TiAlN |
| Drill Bit Grouping | Drill Bit |
| Drill Bit Material | Solid Carbide |
| Drill Bit Point Angle | 140 Degrees |
| Drill Bit Point Type | Self-Centering Point |
| Drill Bit Size | 13/32 in |
| Drill Diameter Tolerance | M7 |
| Drill Length Class | Jobber Length |
| Drill Point Length | 1.88mm |
| Drilling Depth | 40.00mm |
| Flute Length | 2 1/8 in |
| Flute Type | Spiral |
| Grade, Material Grade - Machining | K30F |
| Item | Jobber Length Drill Bit |
| List Number | A3382 |
| Material - Machining | Carbide |
| Maximum Drilling Depth | 1 9/16 in |
| Number of Coolant Holes, Number of Flutes | 2 |
| Number of Pieces | 1 |
| Overall Length | 4 in |
| Point Type | Self-centering |
| Primary Material Application | Aluminum, Brass, Bronze, Cast Iron, Copper, Hardened Steel, Nickel, Stainless Steel, Steel, Titanium |
| Primary Material Application ISO Code | H, K, M, N, P, S |
| Secondary Material Application | Composite |
| Secondary Material Application ISO Code | O |
| Series | X.treme Plus |
| Shank Dia. | 12.00 mm |
| Shank Length | 1 3/4 in |
| Shank Type - Machining | Straight |
| Sheeter Drill | No |
| Standards | DIN 6537 |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | Zoro | G8142793 | 198.63 | 198.63 | 1 | In Stock | Walter Titex | 0.29 | 198.63 @ Qty: 1+ | |
| AmazonTP | B017BM1GCK | 281.94 | 281.94 | 1 | In Stock | 30 | Walter | 281.94 @ Qty: 1+ | ||
 | sustainablesupply.com | C1422355 | 282.63 | 282.63 | 1 | In Stock | Walter Tools | 0.29 | 282.63 @ Qty: 1+ | |
 | Raptor Supplies | AF8VTX | 376.7592465 | 376.7592465 | 1 | In Stock | WALTER | 376.7592465 @ Qty: 1+ |
