WEG 00236OT3E145JP

B00C710VM2

WEG 00236OT3E145JP JP Type ODP NEMA Premium Efficiency Close Coupled Electric Pump Motor, 2 HP, 3-Phase, 3430 rpm, 208-230/460 V, 60 Hz, Frame 145JP

WEG 00236OT3E145JP JP Type ODP NEMA Premium Efficiency Close Coupled Electric Pump Motor, 2 HP, 3-Phase, 3430 rpm, 208-230/460 V, 60 Hz, Frame 145JPzoom

Attributes

Key Value
ClassificationJM-JP & Jet Pump
Country of Origin (subj.Brazil
DutyContinuous
EnclosureODP
Frame145JP, 143JP
Frame MaterialRolled Steel
Frame RemarksClose Coupled Pump, Foo.
Full Load Amps4.6-5.0/2.5
Green Certification or .NEMA Premium Rated
Green Environmental Att.Product Contributes To .
HP2
Hz60
Ins. ClassF
Inverter RatedYes
ItemClose-Coupled Pump Motor
Item ConditionFactory New
Length Less Shaft11-1/8"
ManufacturerWEG
Max. Ambient Temp.40 Degrees C
Motor ApplicationPump
Motor BearingsBall
Motor Design3-Phase
Motor Efficiency GroupNEMA Premium Efficient
Motor Enclosure DesignOpen Dripproof
Motor Frame MaterialRolled Steel
Motor Mounting TypeFace/Base
Motor Service Factor1.15
Motor Shaft DesignJP Threaded
Motor Shaft RotationCW/CCW
Motor Sub ApplicationClose-Coupled Pump
Motor Thermal ProtectionNone
Nameplate RPM3430
Nominal Efficiency86.5%
Overall Length15-3/8"
Phase3
RPM3600
RPM Range3001-3600
Shaft Dia.7/8"
Shaft Length4-1/4"
StandardsUL Recognized, CSA Cert.
Voltage208-230/460
Voltage Compatibility208, 230, 240, 460, 208.
Volts208/230/460

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG1424665424.731In StockWeg424.73 @ 1
thumbzoomDealers Electric00236OT3E145JP529.561In StockWeg48.0529.56 @ 1
