WIDIA 4IR4RD

B01MRN6OJA

WIDIA 4IR4RD TN6025 Series IR/L-RD Laydown Threading Insert, Carbide, Size 4, Round-Internal, 4 TPI

WIDIA 4IR4RD TN6025 Series IR/L-RD Laydown Threading Insert, Carbide, Size 4, Round-Internal, 4 TPIzoom

Attributes

Key Value
ANSI Code4IR4RD
Chip-BreakerNo
Clearance Angle10 Degrees
Coating ProcessPVD
Corner Radius1.40mm
Country of Origin (subj.Germany
Cutting ApplicationTurning
Cutting DirectionRight Hand
Feed TypeHigh
Finish - MachiningAlTiN
GradeTN6025
Included Angle30 Degrees
Inscribed Circle1/2 in
Insert Holding Type1/2 in
Insert Length22.00mm
Insert ShapeTriangle
Insert Size4
Insert Style4IR
ISO Number4IR4RD
ItemThreading Insert
Manufacturer GradeTN6025
Material - MachiningCarbide
Max. Thread Pitch4
Measurement SystemMetric
Number of Cutting Edges3
Primary Material Applic.Cast Iron, Nickel, Stai.
Primary Material Applic.K, M, P, S
Secondary Material Appl.Aluminum, Brass, Bronze.
Secondary Material Appl.N
Side-to-Cutting Tip1.40mm
StyleRound
Thickness4.76mm
Thread DirectionRight Hand
Thread Height Difference1.40mm
Thread Profile TypeFull
Thread StandardRound DIN 405
Thread TypeRound DIN 405
Threading LocationInternal

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG392968334.161In Stock42Widia0.0234.16 @ 1
