WIDIA 2951400

B01M32YVTK

WIDIA A20UCTFPR3 A-CTFP C-Style Clamping Boring Bar for Positive Inserts, 0? Angle, Steel, 1.25" Shank Diameter, Right, 14" Length,

WIDIA A20UCTFPR3 A-CTFP C-Style Clamping Boring Bar for Positive Inserts, 0? Angle, Steel, 1.25" Shank Diameter, Right, 14" Length,zoom

Attributes

Key Value
ANSI CodeA20UCTFPR3
Approach Angle90 Degrees
Coolant FedCoolant Through
Cutting ApplicationBoring
Cutting DirectionRight Hand
Head MaterialSteel
Insert Cutting Edge Len.16.50mm
Insert Holding TypeClamp
Insert ShapeTriangle
Insert Size322
Insert StyleTP
ISO NumberA20UCTFPR3
ItemIndexable Boring Bar
Lead Angle0 Degrees
Left/Right HandRight Hand
Min. Bore Dia.1.4700 in
Number of Inserts1
Overall Length14 in
Rake-5 Degrees Radial, 0 D.
Shank Dia.1-1/4 in
Shank Length12.3600 in
Shank MaterialHigh Speed Steel
Side Cutting Edge Angle0 Degrees
Toolholder StyleA-CTFP

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG3574083321.61In Stock21Widia4.4321.6 @ 1
