ZEBRA ZT23042-D01A00FZ

B00GRAEETU

ZT230 - 203DPI - DIRECT THERMAL (DT) - US P/C - SERIAL/USB INTERNAL 802.11N W/L - TEAR BAR - ZPL (ITEM ALSO KNOWN AS : ZEB-ZT23042D01A00FZ) [zt23042-d01a00fz]

ZT230 - 203DPI - DIRECT THERMAL (DT) - US P/C - SERIAL/USB INTERNAL 802.11N W/L - TEAR BAR - ZPL (ITEM ALSO KNOWN AS : ZEB-ZT23042D01A00FZ) [zt23042-d01a00fz]zoom

Attributes

Key Value
ApplicationIndustrial
Application/UsageIndustrial
B/W or ColorMonochrome
Barcode Printer TypeIndustrial
Barcode Symbology Suppo.Code 11, Code 39, Code .
Battery SizeNone, 100 to 240V AC
BrandZebra Technologies, Zeb.
Brand NameZebra
Color Printing Capabili.Monochrome
ConnectivityRS-232, USB, Wi-Fi
Connectivity / Wireless.Yes
Country of Origin (subj.China
Depth17, 43.2
Device TypePrint server, Power sup.
Dimensions17"/432 mm x 9.5"/242 m.
Dispensing StyleTear Off
Display ScreenYes
Display Screen TypeLCD
Document & Media Handli.Other
DPI203dpi
DurabilityIndustrial
ENERGY STARYes
Energy StarYes
Environmental Certifica.ENERGY STAR
Environmentally FriendlyYes
FeaturesTear-off, Element Energ.
Features/IncludesReal Time Clock, Adjust.
FilterFilter
Flash Memory128MB, 128 MB
Font SizeScalable
For Core Dia.1 in, 3 in
For Use WithLabel Print
FunctionsPrinter
Geographical Availabili.North America
Height10.9, 10.9", 27.7
Included FeaturesEPL2, ZPL2
IncludesZT230 Industrial Printe.
Input Voltage110 V AC, 220 V AC
InterfaceWi-Fi(n), Serial, USB
Interface OptionsSerial, USB, Wireless
ItemIndustrial Printer
Label Core1 inch, 3 inches
Label Core Size3
Label Formats SupportedContinuous Label, Black.
Language EmulationZPL
Language SimulationZPL II, ZPL, Extensible.
Limited Warranty1 Year
ManufacturerZebra Technologies Corp.
Manufacturer Part NumberZT23042-D01A00FZ
Manufacturer Website Ad.http://www.zebra.com
Max H-Document Size114 mm
Max Label Width4.50
Max Media SizeRoll (11.4 cm)
Max Print Resolution B/W203 dpi
Max Print Speed B/W152
Max Roll Outer Diameter6, 8
Max. Label Length39"
Max. Label Width4.50"
Max. Print Width4.09 in
Max. Ribbon Length1,476 ft
Max. Roll Dia.8"
Max. Tape Width4.09"
Maximum Label Length39
Maximum Label Width4.50
Maximum Media Width0.75"/19.4 mm to 4.50"/.
Maximum Mono Print Speed6 in/s
Maximum Print Resolution203 dpi
Maximum Print Speed6"/152 mm per second, 6.
Maximum Print Width4.09, 4.90, 4.09"/104 m.
Maximum Roll Diameter8
Media HandlingNo Additional Options
Media SensorTransmissive Media Sens.
Media SensorsTransmissive and reflec.
Media Size ClassOther
Media Thickness10 mil
Media TypeContinuous Label, Die-c.
Media TypesContinuous, die-cut, no.
Memory TechnologyDRAM
MFG Part NumberZT23042-D01A00FZ
ModelZT230
Nominal VoltageAC 120/230 V
nullnull
Operating Temperature32?F to 105?F/0?C to 40.
Overall Depth17 in
Overall Height10-29/32 in
Overall Width9-1/2 in
Packaged Quantity1
Platform SupportedPC
Power SourceAC Supply, Electrical A.
Print Color CapabilityMonochrome
Print Length157"/3988 mm
Print MethodDirect Thermal
Print Resolution203 dpi
Print Speed6 in/sec, 6, 6.0 inches
Print Width4"
Printer ConnectivityRS232, USB
Printer DisplayLCD
Printer MobilityNot Mobile
Printer Resolution203 dpi
Printer SeriesZT200
Printer TypeIndustrial, Standard In.
Printhead Resolution203 dpi
Printing Software Compa.Link-OS, ZBI 2.0, ZPL, .
Product ConditionNew
Product FamilyZT230
Product LineZebra
Product ModelZT230
Product NameZT230 Industrial Printer
Product SeriesZT200
Product TypeDirect Thermal Printer,.
RAM Size128
Recommended UseLabel Print
RegionUnited States
Resolution203 dpi/8 dots per mm
Ribbon Core1
Scanner TypeNone
Screen TypePush Button
Serial PortYes
Service Type1-year warranty
Stand Alone Printing / .PC
Standard Memory128 MB
StandardsIEC 60950, EN 55022 Cla.
Supported Barcode Symbo.ISBT-128, Plessey, EAN-.
Supported MediaLabels, Die cut labels,.
TechnologyDirect Thermal
TypePrinter, Label printer
USBYes
Voltage100 to 240V AC
Weight20 lb, 20 lbs./9.1 kg, .
Weight (Approximate)20 lb
Width9.5", 9.5, 24.2
Wire CommunicationWired
Wired/wirelessWireless, Wired
Wireless LANYes
Wireless LAN StandardIEEE 802.11a/b/g/n
ZebraZT200SeriesDataShe.https://www.advanced-au.

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomadvanced-automationinc.comZT23042-D01A00FZ941.91In StockZebra941.9 @ 1
thumbzoomPCNationPJ8672988.61In StockZEBRA24.0988.6 @ 1
barcodegiant.comZEB190718988.851In StockZebra988.85 @ 1
CDW2734406988.851In StockZebra988.85 @ 1
thumbzoomusmegastore.comZT23042-D01A00FZ988.851In StockZebra20.0988.85 @ 1
thumbzoomGrand and ToyZT23042-D01A00FZ1358.731In StockZEBRA1358.73 @ 1
thumbzoomRadwellZT23042-D01A00FZ1427.281In StockZEBRA25.01427.28 @ 1
thumbzoomZoroG82926571597.811In Stock13Zebra22.71597.81 @ 1
