MEAN WELL PLM-40-1750

B00LS9LQBO

MW Mean Well PLM-40-1750 23V 1750mA 40.25W Single Output LED Power Supply with PFC

MW Mean Well PLM-40-1750 23V 1750mA 40.25W Single Output LED Power Supply with PFCzoom

Attributes

Key Value
AC inrush current (max.)COLD START 15A(twidth=5.
ConfigurationEnclosed
Connection?DG235-7.2-2P
Dimension175 x 42 x 24mm (LxWxH)
Dimensions175 x 42 x 24mm
EMC EMISSIONCompliance to EN55015, .
EMC IMMUNITYCompliance to EN61000-4.
Industry Aliasesnew
Input Voltage115 VAC ; 120 VAC ; 127.
Input Voltage Range110-295 VAC
Inrush Current (Typ.)Cold Start 15A (twidth=.
Isolation ResistanceI/P - O/P, 100M Ohms / .
Leakage Current0.5mA / 240VAC
Mounting TypePanel Mount
Number of Outputs1
OperationSwitching
Output Current1.75 A
Output Power40.3 W
Output Rated Current1750mA
Output Voltage23 VDC, 27V
Over Temperature115?C?5?C (TSW1)
Over temperature protec.Hiccup mode, auto-recov.
Primary TypeAC-DC
Safety standardsUL8750, ENEC EN61347-1,.
SeriesPLM-40 Series
Short CircuitHiccup mode, recovers a.
Special FeaturesConstant Current Operat.
Storage Temp., Humidity-40 ~ +80?C, 10 ~ 95% RH
Temp. Coefficient?0.03%/?C (0 ~ 50?C)
TypeLED Driver
Vibration10 ~ 500Hz, 2G 10min. /.
Wattage40
Withstand VoltageI/P - O/P : 3.75KVAC
Withstand voltageI/P-O/P: 3.75kVAC
Working Humidity20 ~ 95% RH non-condens.
Working Temp.-30 ~ +45?C (Refer to ".

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Onlinecomponents.comPLM-40-175014.4110MEAN WELL14.4 @ 1
thumbzoompeaktopeakpower.comPLM-40-175014.41In StockMean Well14.4 @ 1
us.rs-online.com7038810021.161In StockMEAN WELL21.16 @ 1
thumbzoompowersupplymall.comPLM-40-175033.01In StockMean Well33.0 @ 1
