NTN HPC014GP

B017UJOVGM

NTN HPC014GP , HEX BORE ADAPTER , 4547359476750 UPC

NTN HPC014GP , HEX BORE ADAPTER , 4547359476750 UPCzoom

Attributes

Key Value
ABEC Tolerance1
application:Agriculture Bearing
Bearing MaterialSteel
bearing material:Through Hardened Steel
Bearing TypeHex Bore, Cylindrical O.
Bore Dia.0.875 in
Bore Diameter0.897 in
Bore Size0.897 in
Bore Size Tolerance+/-0.005 in
Bore Tolerance+/-0.005 in
bore type:Hex
BrandNTN
CageSteel
Cage MaterialSteel
cage material:Steel
closure type:Double Seal
Dynamic Load Capacity3,150 lb
dynamic load capacity:3150 lbf
EnclosureDouble sealed
fillet radius:0.0394 in
finish/coating:Uncoated
Flange SizeNot Applicable
For Shaft Size7/8 in
inner ring width:1.0000 in
internal clearance:CN
ItemAgricultural Disc Beari.
LubricationShell Alvania #3
Manufacturer NameN/A
MaterialThrough Hardened Steel
Max. RPM5,900 RPM
Maximum Speed5,900 RPM
Minimum Buy Quantity23153417
operating temperature r.-40 to 250
outer ring width:0.5906 in
Outside Dia.2.0472 in
Outside Dia. Tolerance+0/-0.0005 in
Outside Diameter2.047 in
outside diameter design:Straight
Overall Width1 in
precision rating:ISO Class 0
Seal MaterialNitrile Rubber
series:HPC
Static Load Capacity1,750 lb
static load capacity:1760 lbf
Temp. Range-13 Degrees to 250 Deg.
UNSPSC0.163
Weight / KilogramB00308
Width1.0 in

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomindustrialzone.comHPC014GP23.599In StockNTN1.023.59 @ 9
thumbzoommotionindustries.com0014726734.851In StockNTN34.85 @ 1
thumbzoomZoroG189497744.691In Stock13Ntn0.3944.69 @ 1
thumbzoomBDI ExpressHPC014GP49.764611831In StockNTN0.358649.76461183 @ 1
thumbzoomsustainablesupply.comC169081750.581In StockNTN0.3950.58 @ 1
thumbzoomRaptor SuppliesAE2YTN78.98547151In StockNTN78.9854715 @ 1
thumbzoomMRO Supply274940195.861In StockNTN Bearing195.86 @ 1
