Molex / Waldom 39-30-6168

B07QPBKXKP

39-30-6168, 4.20mm Pitch Mini-Fit Jr. Header, Dual Row, Vertical, with Snap-in Plastic Peg PCB Lock, 16 Circuits, PA Polyamide Nylon 6/6. (25 Items)

39-30-6168, 4.20mm Pitch Mini-Fit Jr. Header, Dual Row, Vertical, with Snap-in Plastic Peg PCB Lock, 16 Circuits, PA Polyamide Nylon 6/6. (25 Items)zoom

Attributes

Key Value
ApplicationsGeneral Purpose, Indust.
Base Product Number003930
CategoryConnectors, Interconnec.
ColorNatural
Connector TypeHeader
Contact FinishTin Plated
Contact Finish - MatingTin
Contact Finish - PostTin
Contact Finish Thicknes.100.0?in (2.54?m)
Contact Finish Thicknes.100.0?in (2.54?m)
Contact Length - Mating-
Contact Length - Post0.138" (3.50mm)
Contact MaterialBrass
Contact Plating Thickne.2.54 ?m
Contact ShapeSquare
Contact TypeMale Pin
Current Rating9 A
Current Rating (Amps)-
DescriptionCONN HEADER VERT 16POS .
Detailed DescriptionConnector Header Throug.
Digi-Key Part NumberWM19559-ND
Fastening TypeLocking Ramp
Features-
Flammability RatingUL 94V-0
Hole Center to Center4.2 mm
Ingress Protection-
Insulation ColorNatural
Insulation Height0.504" (12.80mm)
Insulation MaterialPolyamide (PA66), Nylon.
ManufacturerMolex
Manufacturer Product Nu.0039306168
Manufacturer Standard L.16 Weeks
Mated Stacking Heights-
MaterialNylon
Material Flammability R.UL94 V-0
Max. Temp.240?C
Max. Voltage600V
MfrMolex
Mounting TypeThrough Hole
Number of Contacts16
Number of Positions16
Number of Positions Loa.All
Number of Rows2
Operating Temperature-
Overall Contact Length-
PackageTray
Package Quantity1
Pitch - Mating0.165" (4.20mm)
Product StatusActive
Row Spacing - Mating0.165" (4.20mm)
SeriesMini-Fit Jr 5566
ShroudingShrouded - 4 Wall
StandardsCSA Certified; UL E29179
StyleBoard to Cable/Wire
Terminal FinishTin Plated
Terminal TypeThrough Hole
TerminationSolder
Voltage Rating-

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
WaldomMOLEX 39-30-61681.65353771MOLEX1.65 @ 35
Onlinecomponents.com39-30-61681.8512633MOLEX / WALDOM1.85 @ 25
Newark48T66431.99192025MOLEX1.99 @ 1920
jensentools.com101885622.2125Molex2.2 @ 25
thumbzoomDigi-Key31602163.21453Molex3.2 @ 25
thumbzoomZoroG4037668101.153525Molex101.15 @ 35
