Panduit LCBX300-38H-6

B00B5OBPBS

Panduit LCBX300-38H-6 Flex Conductor Lug, One Hole, Long Barrel With Window, 45 Degree Angle, 300 kcmil Class G/H/I/K/M Conductor Size, 313.1 kcmil Diesel Locomotive Conductor Size, 3/8" Stud Hole Size, Red Color Code, 2-3/8" Wire Strip Length, 0.18" Tongue Thickness, 1.39" Tongue Width, 2.30" Neck Length, 3.42" Overall Length

Panduit LCBX300-38H-6 Flex Conductor Lug, One Hole, Long Barrel With Window, 45 Degree Angle, 300 kcmil Class G/H/I/K/M Conductor Size, 313.1 kcmil Diesel Locomotive Conductor Size, 3/8" Stud Hole Size, Red Color Code, 2-3/8" Wire Strip Length, 0.18" Tongue Thickness, 1.39" Tongue Width, 2.30" Neck Length, 3.42" Overall Lengthzoom

Attributes

Key Value
Base Product NumberLCBX
CategoryConnectors, Interconnec.
ColorRed
Contact FinishElectro-Tin
Contact MaterialCopper
Country of Origin (subj.Mexico
Diameter - Barrel ID0.760" (19.30mm)
Diameter - Barrel OD0.950" (24.13mm)
Diameter - Ring ID0.410" (10.41mm)
Features-
InsulationNon-Insulated
Length - Overall-
MfrPanduit Corp
Mounting TypeFree Hanging (In-Line),.
PackageBulk
Product StatusObsolete
SeriesPan-Lug?
Stud/Tab Size3/8 Stud
Tab Thickness0.180" (4.57mm)
Terminal StyleSingle Stud Hole
Terminal TypeRectangular Tongue
TerminationCrimp, Barrel
Width - Outer Edges1.390" (35.31mm)
Wire Gauge300MCM (kcmil)

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomgordonelectricsupply.comLCBX300-38H-632.151In Stock12PANDUIT32.15 @ 1
thumbzoomZoroG277722634.81In Stock25Panduit34.8 @ 1
