Nichicon UPM1V101MPD-NICHICON

B00DWIL4T8

NICHICON UPM1V101MPD

NICHICON UPM1V101MPDzoom

Attributes

Key Value
ApplicationsGeneral Purpose
Body dimensions?8x11.5mm
Capacitance100 ?F, 100 uF, 100?F
Capacitance (uF)100
Capacitance Range100 to 999 uF
Capacitor applicationswitching power supplies
Capacitors seriesUPM
Case SizeDia. 0.315 x L 0.453 in.
Case StyleRadial
CategoryCapacitors
ConfigurationRadial ; Can
Diameter (mm)8
Element MaterialAluminum Electrolytic
ESR (Equivalent Series .-
Height (mm)11.5
Height - Seated (Max)0.512" (13.00mm)
Impedance160 mOhms, 0.16?
Kind of capacitorlow ESR
Lead Spacing0.138 In. (3.50 mm) mm,.
Lifetime @ Temp.3000 Hrs @ 105?C
ManufacturerNICHICON
MfrNICHICON
Minimum Operating Tempe.-55 C
MountingTHT
Mounting TypeThrough Hole, PCB Mount
Operating current0.46A
Operating Temperature-55?C ~ 105?C
Operating temperature-55...105?C
Operating voltage35V DC
PackageBulk
Package / CaseRadial, Can
PolarityPolar
PolarizationPolar
Product StatusNot For New Designs
Ratings-
Ripple Current @ High F.460 mA @ 10 kHz
Ripple Current @ Low Fr.305 mA @ 120 Hz
SeriesUPM, UPM Series
Service life2000h
Size / Dimension0.315" Dia (8.00mm)
Surface Mount Land Size-
Temperature (deg C)105
Terminal pitch3.5mm
TerminationThrough Hole
Tolerance?20%, 20% %
Typeelectrolytic
Type of capacitorelectrolytic
Voltage (V)35
Voltage - Rated35 V
Voltage Rating35 VDC
Weight (lbs)(0.0025)

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Future Electronics71784450.09936133410Nichicon0.09936 @ 250
thumbzoomNewark54K96630.1433000250NICHICON0.143 @ 3000
HotendaH2461400.165361250Nichicon0.16536 @ 250
thumbzoomTMEUPM1V101MPD0.17521028NICHICON0.175 @ 250
us.rs-online.com701877450.1894412914Nichicon0.18944 @ 250
thumbzoomBD EnterprisesUPM1V101MPD0.251250Nichicon0.00250.25 @ 250
Digi-Key24280750.29811250Nichicon0.2981 @ 250
