8501RSD34V53

B00DWIFMD2

Square D 8501RSD34V53 Relay 240Vac 5Amp Type R +Options

Square D 8501RSD34V53 Relay 240Vac 5Amp Type R +Optionszoom

Attributes

Key Value
AC Contact Rating - Rel.5 A @ 120/240V, 5A @ 12.
Amperage Rating5
Application8501NR45
ApprovalsCE, CSA, UL
Base Type - Plug In Rel.Square
Body Depth1.07 in
Body Depth - Relay1.16 in
Body Height1.37 in
Body Height - Relay1.28 in
Body Width0.83 in
Body Width - Relay0.91 in
BrandSchneider Electric, Squ.
Catalog Number8501RSD34V53
Coil Voltage24 V DC
Coil Volts24V DC
ConditionNew
ConnectionSpade
Contact Configuration4PDT
Contact Current Rating5 A
Contact Form4PDT
Contact Form - Relay4PDT
Contact MaterialSilver Cadmium Oxide, S.
Contacts4PDT
Country of OriginCN - China, China
Current Rating5 A
DC Contact Rating - Rel.5 A @ 28V, 5A @ 28V
Depth38.9 mm
ECCNEAR99
EnclosureSealed Plastic
Family SeriesSquare D Relays, 8501R .
FeaturesClass 1 Div. 2, Hermeti.
Flat Pin Width0.09 in
Gross Weight0 lbs
Height29.4 mm
HP @ 120Vnot rated
HP @ 240Vnot rated
HP Ratingnot rated
International ShippingNo
ItemHermetically Sealed Rel.
Item - RelayHermetically Sealed Rel.
Item Number8501RSD34V53
Item TypeLow voltage;Miniature R.
Made in USANo
ManufacturerSquare D, Schneider Ele.
Manufacturer Part Number8501RSD34V53
Materialhermetically sealed sil.
MountingSocket, Plug In
Mounting - RelayPlug In, Plug-In
Mounting TypeSocket Mount
Mpn8501RSD34V53
Net Weight0.11 lbs
Nominal Coil Voltage24 VDC
Number of Pins - Relay14
Operating Temperature-40-131 A Degrees F
Overall Depth1.53 in
Overall Height - Relay1.53 in
Power Consumption - Rel.0.9 W
Primary TypePower Relays
Product Series8501R
Published Coil Voltage24 VDC
Push To TestNo
Rating @ 120 VAC5 A
Rating @ 220/240/277 VAC5 A
Rating @ 24/28/30 VDC5 A
Relay TypeElectromechanical
Safety GuidedNo
Series8501 Series
SKUZO-G2745215
Socket Code - RelayG
Special FeaturesNo indicator;Without te.
StandardUL LISTED-UL RECOGNIZED.
StandardsCE Marked, CSA, UL, CE .
Status IndicatorNo
SubCategoryElectrical
TerminationSpade
Time Cycle20 ms - pick-up || 20 m.
Typelow voltage
UNSPSC39122325
UPC785901031895
UPC Code785901031895
Use With8501NR45
Warranty DescriptionContractual Warranty:18.
Weight2.000000
Width23.1 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Graybar9317372531.34881In StockSquare D (Schneider Electric)31.3488 @ 1
AmazonTPB000LEUKZK60.41In Stock2Square D60.4 @ 1
thumbzoomGalco8501RSD34V53-SQD61.961In StockSquare D0.1161.96 @ 1
thumbzoomindustrialrefrigerationparts.com8501RSD34V5364.991In StockSquare D2.064.99 @ 1
thumbzoomblackhawksupply.com8501RSD34V5366.031In StockSquare D66.03 @ 1
standardelectricsupply.com223146367.991In StockSquare D67.99 @ 1
thumbzoomZoroG274521568.291119Schneider0.1768.29 @ 1
Mouser996-8501RSD34V5372.1118Square D72.1 @ 1
thumbzoomsustainablesupply.comC117844876.921In StockSquare D0.1776.92 @ 1
thumbzoomgordonelectricsupply.com8501RSD34V5378.091In Stock10SQUARE D78.09 @ 1
thumbzoomsimsupply.comZO-G274521579.321In StockSchneider Electric79.32 @ 1
us.rs-online.com7006088880.761In StockSquare D80.76 @ 1
steinerelectric.com6157381.281In StockSquare D?81.28 @ 1
thumbzoomcrescentelectric.com16279883.271In StockSquare D by Schneider Electric83.27 @ 1
thumbzoomNewark16B658499.741In StockSQUARE D BY SCHNEIDER ELECTRIC99.74 @ 1
thumbzoomNational Supply Network69532711115.351In StockSquare D115.35 @ 1
grainger.caSQD8501RSD34V53125.027341561In StockSQUARE D0.17125.02734156 @ 1
thumbzoomRaptor SuppliesAF9FVA151.5797011In StockSQUARE D151.579701 @ 1
