TDK-Lambda CC10-2412DF-E

B005S3X9MK

TDK LAMBDA CC-10-2412DF-E Isolated Board Mount DC/DC Converter, DIP, Through Hole, Adjustable, 36 V, 18 V, 2

TDK LAMBDA CC-10-2412DF-E Isolated Board Mount DC/DC Converter, DIP, Through Hole, Adjustable, 36 V, 18 V, 2zoom

Attributes

Key Value
ApplicationsITE (Commercial)
ASINB005S3X9MK
Base Product NumberCC10-2412
Body dimensions35.56x22.61x8.51mm
CaseDIP7
CategoryPower Supplies - Board .
ConfigurationOpen-Frame
Control FeaturesEnable, Active Low
Current - Output (Max)450mA, 450mA
Dimensions1.4 L x 0.89 W x 0.33 H.
Efficiency-, 71...90%
Features-
Input Voltage24
Input voltage24V
IsolationIsolated
Isolation Voltage0.5kV (500V)
Item model numberCC10-2412DF-E
ManufacturerTDK-LAMBDA
Manufacturer seriesCC-E
MfrTDK-Lambda Americas Inc
MountingTHT
Mounting TypePCB Mount ; Through Hol.
Number of Outputs2
Operating Temperature-40?C ~ 85?C, -40 Deg. .
Operating temperature-40...85?C
Output12VDC@0.45A, -12VDC@0.4.
Output current450mA
Output current 2450mA
Output Power10.8 W
Output Voltage12 VDC, -12 VDC
Output voltage12V DC
Output voltage 2-12V DC
PackageTray
Package / Case7-DIP Module
Part StatusActive
Power10W
Power (Watts)10 W
Primary TypeDC-DC
Product HeaderCC-E Series DC-DC Conve.
Protectionanti-overload OPP
SeriesCC Series, CC-E (10W)
Size / Dimension1.40" L x 0.89" W x 0.3.
Special FeaturesOutput Trim ; Remote On.
TypeIsolated Module, Embedd.
Type of converterDC/DC
Voltage - Input (Max)36V
Voltage - Input (Min)18V
Voltage - Isolation500 V
Voltage - Output 112 ~ 15V
Voltage - Output 2-12 ~ -15V
Voltage - Output 3-

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
RS Delivers237-740720.54412TDK-Lambda20.544 @ 2
thumbzoomTMECC10-2412DF-E26.9812TDK-LAMBDA26.98 @ 2
Digi-Key92040027.57502TDK-Lambda Americas Inc27.57 @ 2
thumbzoomNewark05M696028.19102TDK-LAMBDA28.19 @ 10
us.rs-online.com7017716336.4518TDK-Lambda36.45 @ 2
thumbzoomAmazonSCB005S3X9MK47.0712tdk-lambda47.07 @ 2
