ABB SU202M-C20

mpnSU202M-C20
brandname: ABB
manufacturername: ABB

Abb Controls Product ?SU202M-C20

Brand: ABB
PartNumber: SU202M-C20
Size: One Size
Manufacturer: ABB
Label: ABB

Attributes

Key	Value
AC Voltage Rating	240V AC
Alarm Switch	Optional
Amperage Rating	20, 20 A
Amps	20 A, 20
Application	Branch Circuit Protecti.
Approvals	UL 489, CSA, UL
Auxiliary Switch	Optional
Busbar	Optional
Characteristic	C Curve
Circuit Breaker Actuator	Toggle
Circuit Breaker Mountin.	DIN Rail
Color	Gray, Light gray
Connection type	Screw
Country of Origin (subj.	Hungary
CSA Standard	22.2
Current Rating	20 A
Curve Type	C
DC Voltage Rating	110V DC
Depth	2.67 in
Dimensions	111 mm H x 35 mm W x 69.
Enclosure Type	IP20/IP40
Estimated Weight	0.55
Family Series	ABB Circuit Breakers, S.
Frame Size	32A/EP
Frequency Rating	50/60, 50/60 Hz
Gross Weight	0.545 lbs
IEC Standard	60947-2
Insulation Type	Class II
Interrupt Rating	10, 10 kA
Interrupt Rating AC	10 kA
Item	IEC Miniature Circuit B.
Item Number	SU202M-C20
kAIC @ 240 VAC	10
kAIC @ 277/480 VAC	10
Length	4.56 in
Length (Straight Wirewa.	4.56 in
Manufacturer	ABB
Manufacturer Part Number	SU202M-C20
Max Voltage	240 VAC, 277/480 VAC, 4.
Max. AIR Rating	10kA at 240V AC
Max. Operating Temp.	131 Degrees F
Max. Wire Size	8 AWG
Meets UL Type	UL 489
Min. Operating Temp.	-13 Degrees F
Min. Wire Size	14 AWG
Mounting	DIN Rail
Mounting type	DIN Rail
Mounting Type	DIN Rail Mount
Net Weight	0.545 lbs
Neutral Pole	No
Number of Poles	2
Phase	1
Poles	2
Product Series	SU200M
Protection	Branch Circuit
RoHS	No
Series	SU200M, EP100 ULH, SU20.
Shunt Trip	Optional
Standards	EN/IEC 60947-2 , UL Lis.
Temperature Rating (Deg.	-25 to 55, -25 to 55 de.
Terminal Connection	Screw Clamp
Terminal Type	Screw
Terminals Included	Line and Load
Trip Curve	C
Trip Type	Thermal Magnetic, C-Cur.
Trip Unit	Fixed Thermal / Fixed M.
Type	High Performance, Trip .
UL Standard	489
Undervoltage Release	No
UPC Code	4016779931113
Voltage Rating	480 ; 480 ; 277 ; 96 V,.
Volts AC	277, 480Y
Volts DC	96
Width	1.42 in
Wire Size	18 to 4 AWG, 18 to 8

All Prices

Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
Walker Industrial	SU202M-C20	72.43	1	In Stock	17	ABB		72.43 @ 1
Airline Hydraulics	ABB SU202M-C20	75.29	1	In Stock		ABB		75.29 @ 1
standardelectricsupply.com	2311079	75.67	1	In Stock		ABB		75.67 @ 1
motorsandcontrol.com	SU202M-C20	78.0	1	In Stock		ABB	0.55	78.0 @ 1
Zoro	G3615857	81.22	1	In Stock		Abb		81.22 @ 1
us.rs-online.com	71079241	81.55	1	38		ABB		81.55 @ 1
alldataresource.com	662770	82.14	1	In Stock		ABB		82.14 @ 1
Radwell	SU202M-C20	85.0	1	In Stock		ASEA BROWN BOVERI		85.0 @ 1
electricalparts.com	SU202M-C20	85.4896	1	12		ABB		85.4896 @ 1
Galco	SU202M-C20-ABBG	88.95	1	In Stock		ABB	0.545	88.95 @ 1
Platt.com	0179691	92.12	1	12		ABB		92.12 @ 1
Newark	63Y5545	96.33	1	In Stock		ABB		96.33 @ 1
