Mean Well USA APV-16-15

B07MF274J1

APV-16-15, AC/DC LED Power Supply - Const Volt - 15W - Fixed: 1,000mA - Dim: No (5 Items)

APV-16-15, AC/DC LED Power Supply - Const Volt - 15W - Fixed: 1,000mA - Dim: No (5 Items)zoom

Attributes

Key Value
AC inrush currentCold start, 70A at 230V.
Approval AgencyCB, CCC, CE, cURus, ENEC
Base Product NumberAPV-16
BrandMean Well
Case Size10
CategoryPower Supplies - Extern.
ConfigurationEnclosed
Connection OutputUL rated, 20AWGx2C (15c.
Current - Output (Max)1A
DescriptionLED DRIVER CV AC/DC 15V.
Detailed Description1A 15V Constant Voltage.
Digi-Key Part Number1866-1147-ND
Digi-Key ProgrammableNot Verified
Dimension (LxWxH)(mm)77x 40x 29
Dimensions77x 40x 29 mm, 3.03(L) .
Dimming-, Analog (0-10V)
Driver TypeConstant-Voltage
Efficiency81%
EMC standardsEN55015, EN61000-3-2 cl.
FeaturesOCP, OVP, SCP
Fixture TypeLED
Industry Aliasesnew
Input Voltage90 ~ 264 VAC Universal,.
Input Voltage Range100-264 VAC
Isolation ResistanceI/P - O/P:>100M Ohms / .
Leakage Current0.25mA / 240VAC
Line Regulation?1.0%
Load Regulation?2.0%
Location RatingDry/Damp
ManufacturerMEAN WELL USA Inc.
Manufacturer Part No.APV-16-15
Manufacturer Product Nu.APV-16-15
Manufacturer Standard L.18 Weeks
Max Output Current1000mA
Max Output Power16W
Max Output Voltage15V
MfrMEAN WELL USA Inc.
Mounting TypePanel Mount, Chassis Mo.
MTBF1145.7K hrs min. MIL-HD.
Number of Outputs1
Operating Temperature-30?C ~ 70?C
OperationSwitching
Our Part No.BSFM-APV-16-15
Output Current1 A
Output Power15 W
Output Voltage15 VDC, 15V
Over LoadAbove 105% rated output.
Over Voltage5.75 ~ 6.75V
PackageBox
Power (Watts)15 W
Primary TypeAC-DC
Product StatusActive
Protection TypeHiccup up mode, auto-re.
RatingsIP42
SeriesAPV-16 (16W), APV-16 Se.
Size / Dimension3.03" L x 1.57" W x 1.1.
Special FeaturesClass 2
Storage Temp., Humidity-40 ~ +80?C, 10 ~ 95% RH
Temp. Coefficient?0.03%/?C (0 ~ 50?C)
Termination StyleWire Leads
TopologyAC DC Converter
TypeLED Driver, Constant Vo.
UL ClassClass 2
Vibration10 ~ 500Hz, 5G 12min. /.
Voltage - Input (Max)264VAC
Voltage - Input (Min)90VAC
Voltage - Isolation3.75 kV
Voltage - Output15V
Voltage Range90 ~ 264VAC 127~370VDC
WarrantyManufacturer's 5 Year
Wattage16
Withstand voltageI/P-O/P: 3kVAC
Working Humidity20 ~ 90% RH non-condens.
Working Temp.-30 ~ +70?C (Refer to ".

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
WaldomMEAN WELL APV-16-154.412120MEAN WELL4.4 @ 120
Onlinecomponents.comAPV-16-155.131120MEAN WELL5.13 @ 120
thumbzoompeaktopeakpower.comAPV-16-157.051120Mean Well7.05 @ 120
thumbzoomTMEAPV-16-157.131120MEAN WELL7.13 @ 120
thumbzoompowersupplymall.comAPV-16-157.561120Mean Well7.56 @ 120
us.rs-online.com703870907.681120MEAN WELL7.68 @ 120
thumbzoomNewark68AH88287.941120MEAN WELL7.94 @ 120
thumbzoomDigi-Key77025988.265841120MEAN WELL USA Inc.8.26584 @ 120
electricautomationnetwork.comAPV-16-159.41120MEANWELL9.4 @ 120
thumbzoomballastshop.comBSFM-APV-16-1511.951120Mean Well11.95 @ 120
RS Delivers738-160920.281120Mean Well20.28 @ 120
