MEAN WELL MPD-65A

B00MLTIZNC

MW Mean Well MPD-65A 5V 12V 2.8A 5.5A 60W Dual Output Medical Type Power Supply

MW Mean Well MPD-65A 5V 12V 2.8A 5.5A 60W Dual Output Medical Type Power Supplyzoom

Attributes

Key Value
AC inrush currentCold start 20A
BrandMean Well
ConfigurationOpen Frame
Depth42mm
Dimension (LxWxH)127x76x42
Dimensions127 x 76 x 42 mm
EMC EmissionCompliance to EN55011 (.
EMC ImmunityCompliance to EN61000-4.
EMC standardsEN55032 class B, EN6100.
Industry Aliasesnew
Input Voltage90 ~ 264 VAC Universal,.
Isolation ResistanceI/P - O/P, I/P-FG, O/P-.
Length127mm
Maximum Temperature+55?C
Medical ApprovedYes
Minimum Temperature-10?C
Mounting TypeChassis Mount
MTBF291.3K hrs min. MIL-HDB.
Number of Outputs2
Output Current2.8 A, 5.5 A
Output Rated Current5.5A and 2.8A
Output Voltage5V, 12V, 5 V dc, 12 V dc
Overload protectionAbove 119% rated output.
Package TypeOpen Frame
Power Rating61W
Primary TypeAC-DC
SeriesMPD Series
Setup, rise, hold up ti.800ms, 20ms, 60ms
StockStock
TypeMedical
Vibration10~500Hz, 2G 10min./1cy.
Wattage65
Weight250g
Width76mm
Withstand VoltageI/P - O/P : 4KVAC-----I.
Working temperature-10~+60?C

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Onlinecomponents.comMPD-65A24.711In StockMEAN WELL24.71 @ 1
Sager ElectronicsMPD-65A26.02200In StockMean Well26.02 @ 200
AmazonTPB07CJQC9X531.341In Stock2Meanwell Guangzhou / Suzhou / Taiwan31.34 @ 1
thumbzoompeaktopeakpower.comMPD-65A38.361In StockMean Well38.36 @ 1
thumbzoomDigi-Key1866-3448-ND39.891In StockMEAN WELL USA Inc.39.89 @ 1
thumbzoompowersupplymall.comMPD-65A47.261In StockMean Well47.26 @ 1
us.rs-online.com7046255653.162002MEAN WELL53.16 @ 200
thumbzoomRS Delivers753-771790.3961In StockMean Well90.396 @ 1
