- mpn200-5000-1-2-2-7
- brandname: NOSHOK
- manufacturername: NOSHOK
NOSHOK 200 Series High Performance Voltage Output Pressure Transducer, <= 5000, 10-30 VDC, 0-5 VDC Output, 0-5000 psig Pressure Range, +/-0.5% Accuracy, 1/4" NPT Male
- Brand: NOSHOK
- PartNumber: 200-5000-1-2-2-7
- Model: 200-5000-1-2-2-7
- PackageQuantity: 1
- Binding: Misc.
- Manufacturer: NOSHOK, Inc.
- Label: NOSHOK, Inc.
Attributes
| Key | Value |
|---|
| Accuracy | 0.5 % |
| Accuracy - Transmitter | +/-0.5% BFSL |
| Adjustment | 10% full scale for zero. |
| Ambient Temperature Ran. | -40 to 185?F, -40 to 185 |
| Application | HVAC, Hydraulics & Pneu. |
| Approvals | CE |
| Approximate Weight | 3.5 |
| Assembly Options | NOSHOK offers multiple . |
| Burst Pressure | 4 Times Full Scale |
| Category | 200 Series Voltage Outp. |
| Compensated Temperature. | 32 to 176?F, 32 to 176 |
| Connection Material | 316 Stainless Steel |
| Connection Size | 1/4 |
| Connection Type | Male National Pipe Thre. |
| Digital Indicators | NOSHOK Digital Indicato. |
| Distribution Manifolds | NOSHOK`s Distribution M. |
| Effect | 0.017% full scale/F for. |
| Electrical Connection | DIN EN 175301-803 Form . |
| Electrical Connections . | DIN EN 175301-803 Form C |
| Electrical Protection | Reverse polarity, over-. |
| Environmental Rating | Ingress Protection (IP6. |
| Family Series | NOSHOK Transducers, 200. |
| Full Scale Best Fit Str. | 0.5 |
| Gauge Connection Size | 1/4 in |
| Gauge Connection Type | MNPT |
| Gross Weight | 0 lbs |
| Housing | 316 Stainless Steel |
| Housing material | 316 Stainless Steel |
| Industry Standards/Cert. | European Conformity (CE. |
| Input | 10-30 VDC |
| IP Rating | IP65 |
| Item Number | 200-5000-1-2-2-7 |
| Load Limitations | >=5,000 ? for 0 Vdc to . |
| Manufacturer | NOSHOK |
| Manufacturer Part Number | 200-5000-1-2-2-7 |
| Max Pressure (Gauge) | 5,000 psi |
| Max. Pressure (PSI) | 5000 psig |
| Measuring Element | 316 stainless steel for. |
| Media Temperature Range | -22 to 212?F, -22 to 212 |
| Min. Operating Temperat. | -40?C |
| Net Weight | 0 lbs |
| Operating Temp. | -40 to 212?F |
| Operating Temperature [. | 100 |
| Operating Temperature [. | -40 |
| Output | 0 to 5V DC, 0-5 VDC |
| Output Signal | 0 Vdc to 5 Vdc, 3-wire |
| Power Supply | 10 Vdc to 30 Vdc (0 Vdc. |
| Powered By | 10 to 30V DC |
| Pressure Connection | 1/4 NPT Male |
| Pressure Cycle Limit | <=1 ms (between 10% and. |
| Pressure Range | 0 to 5,000 |
| Pressure Range (Gauge) | 0-5,000 psi |
| Price: | $520.10 |
| Product Series | 200 |
| Proof Pressure | 1.75 Times Full Scale |
| Related Items | 102-MFS, 100 Series 10,. |
| Response Time | <=1 ms (between 10% and. |
| SchemaID | 105905 |
| Series | 200 |
| Service Life | Greater Than 100,000,00. |
| Shock | 1000G |
| Shock According to Inte. | 1,000 |
| Specification | European Conformity (CE. |
| Stability | <=0.2% full scale per y. |
| Syndication | 1 |
| Temperature Range | -40-185 ?F |
| Transmitter Type | Pressure Transducer |
| Type | Pressure Transducer |
| Unit | 1 |
| Vibration | 20G |
| Vibration According to . | 20 |
| Wetted Materials - Tran. | 316 Stainless Steel |
