Phoenix.. 2320092

B00DDFG3WS

Isolated DC/DC Converters QUINT-PS/24DC/ 24DC/10

Isolated DC/DC Converters QUINT-PS/24DC/ 24DC/10zoom

Attributes

Key Value
Alternate Manufacturer .QUINT-PS/24DC/24DC/10
Alternate Mfr Part Numb.QUINT-PS/24DC/24DC/10
Alternate Part No.651-2320092
Amperage Rating14A
ApplicationsITE (Commercial)
Approval AgencycULus, VDE
ApprovalsUL Listed ; cUL Listed .
Battery Operation Outpu.24 VDC
Body dimensions48x130x125mm
BrandPHOENIX CONTACT
CategoryPower Supplies - Extern.
ComponentDC-DC converter
ConfigurationEnclosed
Country of OriginCN - China
Current - Output (Max)10A
DC Voltage - Input (Max)32V
DC Voltage - Input (Min)18V
DescriptionDC/DC DIN RAIL SUPPLY 2.
Digi-Key Part Number277-9230-ND
Dimensions4.92 in x 1.89 in x 5.1.
ECCNEAR99
Efficiency92%
Height5.12 in
Input TypeDC
Input voltage18...32V
Input Voltage18 to 32
Input Voltage Range18 VDC to 32 VDC
Input Voltage-nominal24 VDC
Insulation voltage1.5kV
IP ratingIP20
Length4.92 in
LineQUINT
ManufacturerPHOENIX CONTACT
Manufacturer Part No.2320092
Manufacturer Product Nu.2320092
MfrPHOENIX CONTACT
Mountingfor DIN rail mounting
Mounting StyleDIN Rail
Mounting TypeDIN Rail Mount
Nominal Voltage24 VDC
Number of Outputs1
Operating temperature-25...75?C
Operating Temperature-25?C ~ 60?C
Operating Temperature R.- 25 C to + 70 C
OperationSwitching
Output24VDC@10A
Output Amperage10 A
Output current10A
Output Current-Channel 110 A
Output Power24 W, 240 W
Output Voltage24 VDC
Output voltage24V DC
Output voltage range18...29.5V DC
Output Voltage-Channel 124 VDC
PackageBulk
Part # AliasesQUINT-PS/24DC/24DC/10 Q.
PLC Input Voltage24 V DC
Power240W
Power (Watts)240W
Power Supply Amperage O.10 Amp
Power Supply Amperage R.6-10 Amp
Power Supply Connection.Screw Connections
Power Supply High Tempe.70 ?C
Power Supply HousingEnclosed
Power Supply Low Temper.-25 ?C
Power Supply MountingDIN Rail Mount
Power Supply Number of .Single Output
Power Supply Voltage In.18 VDC - 32 VDC
Power Supply Voltage Ou.24 VDC
Primary TypeDC-DC
ProductIsolated
Product CategoryIsolated DC/DC Converte.
Product StatusActive
SeriesQUINT, QUINT-PS, QUINT .
Size / Dimension4.92" L x 1.89" W x 5.1.
Special FeaturesSelective Fuse Breaking.
TradenameQUINT POWER
TypeIndustrial
Type of converterDC/DC
UNSPSC39121041
UPC Code4046356481885
Voltage - Output 124V
Voltage - Output 2-
Voltage - Output 3-
Voltage - Output 4-
Voltage - Output 5-
Voltage - Output 6-
WarrantyLimited Lifetime Warran.
Width48 mm, 1.89 in

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomNex Instrument2320092330.01In Stock31PHOENIX330.0 @ 1
thumbzoomNewark33AC1105337.93172PHOENIX CONTACT337.93 @ 1
Onlinecomponents.com2320092342.7812Phoenix Contact342.78 @ 1
RS Delivers739-7904371.9521In StockPhoenix Contact371.952 @ 1
AmazonTPB006WNG1PM380.111In Stock1PHOENIX CONTACT380.11 @ 1
Radwell2320092395.821In StockPHOENIX CONTACT395.82 @ 1
thumbzoomkempstoncontrols.co.uk2320092399.6537481In StockPhoenix399.653748 @ 1
electricautomationnetwork.comQUINT-PS/24DC/24DC/10422.371In StockPHOENIX_CONTACT422.37 @ 1
thumbzoomCarlton Bates Company78037330511470.4912PHOENIX CONTACT470.49 @ 1
AmazonSCB00DDFG3WS526.91In StockPhoenix..526.9 @ 1
thumbzoomTMEQUINT-PS/24DC/24DC533.991In StockPHOENIX CONTACT533.99 @ 1
us.rs-online.com70239257547.471In StockPhoenix Contact547.47 @ 1
rspsupply.comPHOENIX 2320092548.11In StockPhoenix Contact548.1 @ 1
Airline HydraulicsPHOENIX 2320092563.891237Phoenix Contact563.89 @ 1
Graybar25514788584.50561In StockPhoenix Contact584.5056 @ 1
thumbzoomDigi-Key3604969676.68125Phoenix Contact676.68 @ 1
thumbzoomswatee.com2320092694.4514Phoenix Contact694.45 @ 1
