Rexnord MF9303

B00BJP3AG6

Rexnord MF9303 Flange Block, 4-Bolt Flange, Adapter Mounted, Non-Expansion, Heavy Contact Seals, Cast Iron, 3-3/16" Shaft-Size, 8-5/16" Bolt Spacing, 11-3/4" Bolt Circle

Rexnord MF9303 Flange Block, 4-Bolt Flange, Adapter Mounted, Non-Expansion, Heavy Contact Seals, Cast Iron, 3-3/16" Shaft-Size, 8-5/16" Bolt Spacing, 11-3/4" Bolt Circlezoom

Attributes

Key Value
bearing type:Spherical Roller
Bolt Spacing8.313 Inch | 211.15 Mil.
Bore3.188 Inch | 80.975 Mil.
bore type:Round
BrandREXNORD
Cartridge Pilot Depth0 Inch | 0 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
CategoryFlange Block Bearings
EAN698210701611
Expansion / Non-expansi.Non-expansion
expansion type:Non-Expansion Bearing (.
finish/coating:Powder Coated
flange mounting type:Four-Bolt Square
Global Part Number GPN555152
Harmonized Tariff Code8483.20.40.80
Housing Configuration1 Piece Solid
Housing MaterialCast Iron
housing material:Cast Iron
Housing Style4 Bolt Square Flange Bl.
Inch - MetricInch
Insert Part Number9303U
Length Thru Bore5.313 Inch | 134.95 Mil.
locking device:Adapter Mounted
lubrication type:Lubrication Fitting
Manufacturer NameREXNORD
maximum rpm:1200 RPM
Mounting Bolts1 Inch
Mounting MethodTapered Adapter Sleeve
Nominal Bolt Circle Dia.11.7 Inch | 297 Millime.
Number of Mounting Holes4
Other FeaturesDouble Row
overall depth:5-5/16 in
Pilot ConfigurationNo Pilot
price$ 3,823.23 / each
radial dynamic load cap.118000 lbf
radial static load capa.127500 lbf
RelubricatableYes
seal type:Contact/Lip
SealsHeavy Contact
series:9000
standards met:ANSI/ABMA STD 9-1990
titleMF9303
UNSPSC31171501
Weight / LBS66

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomLily BearingMF93033249.751In StockREXNORD66.03249.75 @ 1
thumbzoommotionindustries.com005739984795.751In StockRexnord4795.75 @ 1
