Johnson Controls T-4506-202

mpnT-4506-202
brandname: Johnson Controls
manufacturername: Johnson Controls

Johnson Controls T-4506-202 Dual Temperature Thermostat with Indexing Switch, Direct Acting, Vertical Mounting,

Brand: Johnson Controls
PartNumber: T-4506-202
Model: T-4506-202
PackageQuantity: 1
Binding: Misc.
Manufacturer: Johnson Controls
Label: Johnson Controls

Attributes

Key	Value
1 Pipe / 2 Pipe	2 Pipe
Action	Direct
Action Type - Pneumatic.	Direct Acting
Air Connection Outside .	1/8 in
Air Connections	5/32 in Barb
Air Consumption	20 scim
Air Flow Capacity	400 scim
Air Flow Output	High Volume
Application	Heat or Cool
Best Sellers Rank	See Top 100 in Tools & .
Brand	Johnson Controls
Comments	Vertical Mounting
Control Air Pressure	3 to 15 psi
Control Air Pressure Se.	13 psig (Day)/ 25 psig .
Control Type	Dial, Exposed Dial
Country of Origin (subj.	United States
Cover Included	No
Date First Available	June 28, 2012
Depth	1 3/4 in
Differential Type	Adjustable
Family Series	Johnson Controls Thermo.
Fitting Connection	Barbed 5/32 in
Gross Weight	0 lbs
Heating / Cooling	Heating and Cooling
Height	2 3/32 in
Includes Cover	No
Item	Pneumatic Thermostat
Item Dimensions LxWxH	4 x 4 x 3 inches
Item model number	T-4506-202
Item Number	T-4506-202
Item Weight	1 Pounds
Key Features	Element Identification .
Manual Indexing Switch	Yes
Manufacturer	Johnson Controls
Manufacturer Part Number	T-4506-202
Material	HAWA
Max. Air Pressure	25 psi
Max. Ambient Temp.	135 Degrees F
Maximum Air Pressure	25 psig
Maximum Control Tempera.	85 Degrees F
Minimum Control Tempera.	55 Degrees F
Mounting Direction	Vertical
Mounting Location	Wall
Mounting Style	Vertical
Net Weight	0 lbs
No. of Pipes	2 Pipe
Number of Dials	Dual
Number of Pipes	2
Overall Depth	1 3/4 in
Overall Height	2 1/8 in
Overall Width	3 1/8 in
Pneumatic Thermostat Ty.	Day/Night
Product Dimensions	4 x 4 x 3 inches; 1 Pou.
Product Series	T-4506 Dual Temperature.
Product with faster shi.	true
Reverse Acting / Direct.	Direct Acting
Sensor Type	Bi-Metallic Spring
Setpoints	Day/Night
Shipping	undefined (Fixed Shippi.
Single Temp. / Dual Tem.	Dual Temperature
Temp Setting Range (F)	55-85 ?F
Temp. Control Range	55 Degrees to 85 Degre.
Temperature Output Sett.	Dual Temperature
Temperature Scale	Celsius/Fahrenheit
Temperature Sensitivity	0.75 to 4.0 psig/ Degre.
Temperature Settings	Dual Temperature
Thermostat Action	Direct - 15 psig (Day),.
Thermostat Application	Heating and Cooling
Throttling Range	1 to 5 psi
Weight	1.00, 0.50
Width	3 1/8 in

All Prices

Seller	Supplier SKU	Min Price	MOQ	In Stock	Brand	Weight	Preferred Tier
homeessentialsdirect.com	T-4506-202	59.91	1	In Stock	Johnson Controls		59.91 @ 1
sustainablesupply.com	C1121830	231.58	1	In Stock	Johnson Controls	0.38	231.58 @ 1
waterpumpsnow.com	T-4506-202	278.3	1	In Stock	Johnson	2.0	278.3 @ 1
cappusa.com	119674	282.14	1	5	Johnson Controls		282.14 @ 1
Zoro	G7233773	284.99	1	In Stock	Johnson Controls	0.38	284.99 @ 1
hvacdiscountstore.com	JOH--T-4506-202	294.33	1	7	JOHNSON CONTROLS		294.33 @ 1
alliedcontrols.com	T-4506-202	302.57	1	In Stock	Johnson Controls		302.57 @ 1
grainger.ca	JHCT4506202	314.32480442	1	In Stock	JOHNSON CONTROLS	0.38	314.32480442 @ 1
blackhawksupply.com	T-4506-202	326.51	1	In Stock	Johnson Controls		326.51 @ 1
midwestapplianceparts.com	T-4506-202-JO-P	328.14	1	5	Johnson Controls		328.14 @ 1
Radwell	T-4506-202	330.0	1	9	JOHNSON CONTROLS		330.0 @ 1
gsistore.com	T-4506-202	333.8	1	7	Johnson Controls		333.8 @ 1
Galco	T-4506-202-JHSN	384.81	1	In Stock	Johnson Controls		384.81 @ 1
furnacepartsource.com	T-4506-202	388.95	1	In Stock	Johnson Controls		388.95 @ 1
Voomi Supply	T-4506-202	388.95	1	In Stock	Johnson Controls		388.95 @ 1
industrialstores.com	T-4506-202	395.17	1	2	Johnson Controls		395.17 @ 1
State Supply	JC1272	457.59	1	2	Johnson Controls	0.5	457.59 @ 1
Kele	T-4506-202	457.6	1	In Stock	Johnson Controls		457.6 @ 1
