Schneider Electric QJP32200TM

B00CONENP4

SCHNEIDER ELECTRIC Molded Case Circuit Breaker 240-Volt 200-Amp QJP32200TM Hdm 6200 1Encl 120/208/240V 3Ph 1Mtr

SCHNEIDER ELECTRIC Molded Case Circuit Breaker 240-Volt 200-Amp QJP32200TM Hdm 6200 1Encl 120/208/240V 3Ph 1Mtrzoom

Attributes

Key Value
[Ue] Rated Operational .240 V AC 50/60 Hz UL
[Uimp] Rated Impulse Wi.8 kV UL
Actuator TypeOperating Handle
Ambient Air Temperature.40-70 ?C
Amperage200
Amperage Rating200
Applicationdistribution
ApprovalIEC, UL, CSA, NEMA, NOM
BrandSquare D
Breaker FeatureMercury Free, PVC Free
Breaking Capacity100 kA 120/208 V AC 50/.
Breaking Capacity CodeJ
California Proposition .DINP, which is known to.
Catalog NumberQJP32200TM
China Rohs RegulationProduct out of China Ro.
ConnectionTerminal nut line;lugs .
Connection TypeBolt-On
Continuous Current Rati.80 %
Control TypeOperating Handle
Country of OriginUnknown
Depth3.93 in
Device Applicationdistribution
Electrical Connectionterminal nut line || lu.
Environmental DisclosureENVPEP1406032EN
Eu Rohs DirectiveCompliant
For Use With225A MPL Lever Bypass M.
FrameJ
FunctionsLong Time and Instantan.
GTIN00785901456216
Halogen Content Perform.Halogen free product
Height6.47, 6.47 in
Height UOMInch
Interrupt Rating100 KA 208Y/120 V AC,20.
Interrupting Rating100kAIC at 120/208VAC
Item Typecircuit breaker
Length3.93
Length UOMInch
Line Rated Current200-200 A, 200 A
Local Signalling1 trip indicator green)
Made in USANo
Magnetic Hold Current1200 A
Magnetic Tripping Curre.2400-2400 A
ManufacturerSchneider Electric
Mechanical Durability1000 cycles loaded || 5.
Mercury FreeYes
Mounting Modeunit mount lug)
Mounting Supportlug
Mounting TypeUnit
Network Frequency50/60 Hz
Number of Poles3
Phase3
Poles3
Poles Description3P
Product CertificationsUL || CSA || NOM
Product NamePowerPacT Q
Product Or Component Ty.circuit breaker
ProtectionThermal Magnetic
Pvc FreeYes
RangePowerPact
Reach RegulationReference contains Subs.
Rohs Exemption Informat.Yes
SeriesPowerPacT Q
Special FeaturesUNIT MOUNT
StandardIEC-UL LISTED-CSA
StandardsRoHS, REACh, UL || CSA .
Sustainable Offer StatusGreen Premium product
Temperature Rating40 to 70 ?C
Terminal ConnectionLoad Side lug
Tightening Torque28-28 N.m 25-150 mm? (A.
Trip Range1200 A,200 A,2400 A
Trip Typethermal-magnetic
Trip Unit Technologythermal-magnetic
UPC785901456216
Utilisation Categorycategory A
Voltage240VAC
Voltage Rating208Y/120 V AC
Warranty18 months
Warranty DescriptionContractual Warranty:18.
Width4.5, 4.5 in
Width UOMInch
Wire GaugeAWG 4 to 300 KCmil
Wire Stripping Length22 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomsuperbreakers.comQJP32200TM2209.112Square D2209.1 @ 1
thumbzoomgordonelectricsupply.comQJP32200TM2590.01In Stock10SQUARE D2590.0 @ 1
thumbzoomZoroG39746742590.01In Stock10Square D10.02590.0 @ 1
thumbzoommayerelectric.comSQDQJP32200TM2669.831In StockSQUARE D2669.83 @ 1
thumbzoomRadwellQJP32200TM2700.01In StockSCHNEIDER ELECTRIC SQUARE D2700.0 @ 1
Newark20K24192743.391In StockSQUARE D BY SCHNEIDER ELECTRIC2743.39 @ 1
thumbzoomcrescentelectric.com7620042870.061In StockSquare D2870.06 @ 1
