V56MLA1206NH

B00M1NJMIU

Varistors 56V 180A 180pF

Varistors 56V 180A 180pFzoom

Attributes

Key Value
Alternate Part No.576-V56MLA1206NH
BrandLittelfuse
Capacitance180 pF
Capacitance @ Frequency180 pF @ 1 MHz
Case Code - in1206
Case Code - mm3216
CategoryCircuit Protection
Clamping Voltage120 V
Current - Surge180 A
Dimensions3.2 mm L x 0.5 mm H
Energy1.0J
Energy (Joules)1 J
Family SeriesLittelfuse Metal Oxide .
Gross Weight0 lbs
Item NumberV56MLA1206NH
ManufacturerLittelfuse
Manufacturer Part No.V56MLA1206NH
Manufacturer Part NumberV56MLA1206NH
Max Applied Voltage DC40 VDC
Max Applied Voltage RMS56 V
Max Clamping Volts120 V
Maximum AC Volts40 V
Maximum DC Volts56 V
MfrLittelfuse Inc.
MountingSMD/SMT
Mounting TypeSurface Mount, MLCV
Net Weight0 lbs
Number of Circuits1
Operating Temperature-55?C ~ 125?C (TA)
Operating Temperature R.- 55 C to + 125 C
PackageTape & Reel (TR)
Package / Case1206 (3216 Metric)
Package/Case1206 (3216 Metric)
PackagingReel
Peak Current3 A
Peak Surge Current180 A
ProductMLV
Product CategoryVaristors
Product SeriesMLA
Product StatusActive
RoHSYes
SeriesMLA
Surge Energy Rating1 J
Termination StyleSMD/SMT
Typical Capacitance (pf)18 pF
Varistor Voltage (Max)77 V
Varistor Voltage (Min)61 V
Varistor Voltage (Typ)69 V
Voltage Rating AC40 V
Voltage Rating DC56 V

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomNewark38AC25530.234155LITTELFUSE0.234 @ 1
Future Electronics31462970.4742500253Littelfuse0.474 @ 2500
thumbzoomGalcoV56MLA1206NH-LF0.572500175Littelfuse0.57 @ 2500
HotendaH6156511.13130056Littelfuse1.13 @ 1
Digi-Key26277881.4261175Littelfuse Inc.1.426 @ 1
thumbzoomswatee.comV56MLA1206NH1.8615315Littelfuse1.86 @ 1
