Walter Tools WNMG100612-MK5 WKK10S

B00RXY2N4W

Walter Tools WNMG100612-MK5 WKK10S CVD Coated Solid Carbide Turning Insert, WKK10S Manufacturer Grade, 0.047" Nose Radius, MK5 Chip Breaker, 0.25" Thick (Pack of 10)

Walter Tools WNMG100612-MK5 WKK10S CVD Coated Solid Carbide Turning Insert, WKK10S Manufacturer Grade, 0.047" Nose Radius, MK5 Chip Breaker, 0.25" Thick (Pack of 10)zoom

Attributes

Key Value
ANSI CodeWNMG543-MK5 WKK10S
ANSI NumberWNMG542
Cast Iron (K) Compatibi.Yes
Chip-BreakerYes
Chip-Breaker CodeMK5
Clearance Angle0 Degrees
CoatingCVD
Coating ProcessCVD
Corner Radius1.20mm
Country of Origin (subj.Germany
Cutting ApplicationTurning
Cutting DirectionNeutral
Cutting Edge Length10.86mm
Depth of Cut1.20 to 7.00mm
Finish - MachiningTiCN+Al2O3+TiCN
For Use WithToolholders, Boring Bars
GradeWKK10S
Hardened (H) Compatibil.Yes
Included Angle80 Degrees
Inscribed Circle5/8 in
Insert ApplicationMedium
Insert CodeWNMG543
Insert Holding TypeStraight Hole
Insert MaterialCarbide
Insert ShapeTrigon
Insert Size543
Insert StyleWNMG
Insert Thickness0.2500"
ISO NumberWNMG100612-MK5 WKK10S
ItemTurning Insert
Manufacturer GradeWKK10S
MaterialCarbide
Material - MachiningCarbide
Measurement SystemMetric
Mounting Hole Dia.0.250"
Mounting StyleClamp
No. of Edges2
Non Ferrous (N) Compati.No
Nose Radius0.0470"
Primary Material Applic.Cast Iron
Primary Material Applic.K
RakeNegative
Relief Angle0 Degrees
ShapeTrigon
Stainless (M) Compatibi.No
Steel (P) CompatibilityNo
Super Alloy (S) Compati.No
Thickness4
Through Hole Inside Dia.6.35mm
Workpiece CompatibilityCast Iron (K), Hardened.

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG793256923.241010Walter Valenite0.4623.24 @ 10
