Hubbell HBLDS3MQR

B00N7NAYWG

Hubbell HBLDS3MQR Disconnect, 3P, 30 amp, Unfused, N4X, 1 Motorquick Receptacle

Hubbell HBLDS3MQR Disconnect, 3P, 30 amp, Unfused, N4X, 1 Motorquick Receptaclezoom

Attributes

Key Value
Additional FeaturesStandard Product
Amperage30A
Amperage Rating30, 30 A
Amps AC30 A
ApprovalscUL
AWG Range#14 AWG to #10 AWG
BrandMotor Quick
ColorGray
Component TypeQuick-Disconnect Switch
Contact MaterialTin-Plated Brass
Country of OriginPL - Poland
Current Rating30, 30 A
Depth4.12 in.
Dimenions8.5 in. x 6 in. x 4.12 .
Dimensions8.5 in L x 6 in W x 4.1.
Display TypeStandard Sized Product
ECCNEAR99
Enclosure CompositionMetallic
Enclosure TypeNEMA 4X, NEMA 4X, NEMA .
Family SeriesHubbell Disconnect Swit.
For LocationIndoor, Outdoor
For Use With2DZU9, 2DZV1, 2DZV2, 2X.
FusibleNo
Gender ConfigurationFemale
Gross Weight2.95 lbs
Height8.5 in.
Horsepower15, 15 hp
ItemSwitched Enclosure
Item NumberHBLDS3MQR
ManufacturerHubbell
Manufacturer Part NumberHBLDS3MQR
Max HP 120V 1P1 hp
Max HP 230/240V 3PH7.5 hp
Max HP 240V 1P3 hp
Max HP 460/480V 3PH15 hp
Max HP 600V 3PH15 hp
Max. Voltage600V AC
Maximum Operating Tempe.75 Degrees C
Minimum Operating Tempe.-40 Degrees C
MountingWall
Mounting typeThreaded
NEMA RatingNEMA 4X
Net Weight0 lbs
Number of Poles3
Operator TypeSelector - Red
PhaseThree, 3, 3 ph
Plug EndFemale
Plug Type4-Wire
Poles3
Product TypeSwitched Enclosure
ReceptacleFemale
Short Circuit Current R.65, 65 kA
StandardListed to UL 2238 and U.
StandardscUL US Listed
Switch typeThree Pole Unfused
Switch Type3 Pole
Temperature Rating (Deg.-40, -40 deg C
Terminal TypePressure Screw, Screw
TypeWith Female Receptacle,.
UL ClassUL98
UNSPSC39121521
UPC Code783585310930
Voltage600VAC, 600V AC
Voltage Rating600V AC, 600, 600 V
Width6 in.
Wire Size10 AWG, 12 AWG, 14 AWG

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG2477754445.01In Stock110Hubbell3.05445.0 @ 1
thumbzoomsustainablesupply.comC1184606572.661In StockHubbell3.05572.66 @ 1
thumbzoomMRO Supply1026640582.671In StockHubbell Wiring582.67 @ 1
thumbzoomgordonelectricsupply.comHBLDS3MQR609.01In StockHUBBELL609.0 @ 1
thumbzoomstandardelectricsupply.com2130555624.291In StockHubbell624.29 @ 1
thumbzoomGalcoHBLDS3MQR-HBBL642.651In StockHubbell2.95642.65 @ 1
us.rs-online.com71006142681.6211Hubbell Wiring Device-Kellems681.62 @ 1
thumbzoomcbtcompany.comHBLDS3MQR682.681In StockHubbell Wiring Device-Kellems682.68 @ 1
thumbzoomRadwellHBLDS3MQR720.01In StockHUBBELL KELLEMS720.0 @ 1
Newark16M8849799.711In StockHUBBELL WIRING DEVICES799.71 @ 1
steinerelectric.com397437888.381In StockHubbell888.38 @ 1
Graybar25140352903.49281In StockHubbell Wiring Device - Kellems903.4928 @ 1
kirbyrisk.com21780071057.61In StockHubbell1057.6 @ 1
thumbzoomRaptor SuppliesAC3XEU1089.1257391In StockHUBBELL WIRING DEVICE-KELLEMS1089.125739 @ 1
