HARTING 09120063141

mpn09120063141
brandname: HARTING
manufacturername: HARTING

Harting 09120063141, Crimp, Female, 7 Contacts, Han-Compact, 09120063141

Brand: HARTING
PartNumber: 09120063141
Model: 09120063141
PackageQuantity: 1
Manufacturer: Harting
Label: Harting

Attributes

Key	Value
Alternate Part No.	617-09120063141
Angle	Straight
Application	Industrial Connectors
ASIN	B00TP1J6OG
Base Product Number	09120063
Batteries Required?	No
Brand	HARTING
Category	Connectors, Interconnec.
Color	Gray, Pebble Gray
Connection Type	Crimp
Connector Gender	Female
Connector Type	Insert without Contacts.
Contact Finish	-
Contact Material	-
Contact Type	Han? C, Han? D
Current Rating	40 A
Current Rating (Amps)	-
Description	INSERT FEMALE 4+2POS+1G.
Detailed Description	Female Insert without C.
Digi-Key Part Number	1195-1367-ND
Export Class	EAR / EAR99
Family Name	Industrial Connectors H.
Gender	Female
Hood Orientation	Straight
Housing Material	Polycarbonate, Polycarb.
Includes Poles	No
Insert Color	Gray
Insert Material	Polycarbonate
Insert/Contact Gender	Female
Is Discontinued By Manu.	No
Item	Industrial Rectangular .
Item model number	09120063141
Item Package Quantity	1
Manufacturer	HARTING
Manufacturer Part No.	09120063141
Manufacturer Product Nu.	09120063141
Manufacturer Standard L.	8 Weeks
Material	Polycarbonate
Material Flammability R.	UL94 V-0
Max. Temp.	125?C
Max. Voltage	690V
Maximum Contact Resista.	3 megaohm
Maximum Operating Tempe.	125 Degrees C
Mfr	HARTING
Minimum Insulation Resi.	1.00 x 10^10 ohm
Minimum Mating Cycles	500
Minimum Operating Tempe.	-40 Degrees C
Number of Poles	6
Number of Positions	4 ; 1 PE ; 2 Signal, 4+.
Operating Temperature	-40 to 125 C, -40?C ~ 1.
Package	Bulk
Part # Aliases	006 09 09-12-006-3141 1.
Product Category	Heavy Duty Power Connec.
Product Status	Active
Product Type	Inserts
RoHS	Yes
Series	Han Q, Han Q Series, Ha.
Size	-
Specification	Han UL508 Approved
Standards	DNV GL; EN 60664-1; IEC.
Temperature Range	-40 Degrees C to 125 .
Termination	Crimp
Termination Style	Crimp
Tradename	Han Industrial Connecto.
Type	Socket Insert
Voltage Rating	250V (Signal), 400V (Ea.
Weight (g)	17.00000
Weight (lbs)	0.03748
Wire Size	0.14 to 2.5 sq mm (Sign.

All Prices

Seller	Supplier SKU	Min Price	MOQ	In Stock	Brand	Weight	Preferred Tier
PEI-Genesis	09120063141	19.43	1	20	Harting	0.03748	19.43 @ 1
Carlton Bates Company	78950698879	20.05	1	In Stock	HARTING OF NORTH AMERICA INC		20.05 @ 1
Zoro	G405293141	20.65	1	In Stock	Harting	6.0	20.65 @ 1
Digi-Key	3179950	21.13	1	231	HARTING		21.13 @ 1
TME	09120063141	21.44	1	5	HARTING		21.44 @ 1
us.rs-online.com	70449201	21.67	1	389	HARTING		21.67 @ 1
Newark	99H4165	24.56	1	22	HARTING		24.56 @ 1
AmazonSC	B00TP1J6OG	29.71	1	In Stock	Harting		29.71 @ 1
RS Delivers	512-5362	29.784	1	107	HARTING		29.784 @ 1
swatee.com	09120063141	34.05	1	24	HARTING		34.05 @ 1
