ABB AF09R-30-22-13

mpnAF09R-30-22-13
brandname: ABB
manufacturername: ABB

AF09R-30-22-13 ABB-CONTACTORS,OLS,MMPS AB AF09R302213 REV,3P,9A,100-250VAC

AF09R-30-22-13 ABB-CONTACTORS,OLS,MMPS AB AF09R302213 REV,3P,9A,100-250VAC

zoom

Brand: ABB
PartNumber: AF09R-30-22-13
Manufacturer: ABB
Label: ABB

Attributes

Key	Value
Action	Reversing
Approvals	cULus
Aux. Contact Configurat.	1NO
Auxiliary Contact	2 NO ; 2 NC
Auxiliary Contact Form	1NO
Auxiliary Contacts	1NO, 1NC
Coil Type	Electronic
Coil Voltage	100 VAC, 250 VDC, 100-2.
Coil Volts	240 V AC
Contact Configuration	3NO
Contact Current Rating	25 A
Contact Rating	690
Contact type	Reversing
Control Voltage	600 V
Country of Origin (subj.	Spain
Depth	3.35 in
Dimensions	86 mm H x 45 mm W x 110.
Enclosure NEMA Rating	No Enclosure
Enclosure Type	IP20
Family Series	ABB Contactors, AF Seri.
Frequency Rating	50/60
Full Load Amps-Inductive	10 A
Full Load Amps-Resistive	25 A
General Purpose (AC1)	25 A
Gross Weight	1.725 lbs
Height	3.98 in
HP @ 1 Phase - 120V	1/2 hp
HP @ 1 Phase - 230V	1-1/2
HP @ 1 Phase - 240V	1 1/2 hp
HP @ 3 Phase - 208V	3 hp
HP @ 3 Phase - 240V	3 hp
HP @ 3 Phase - 480V	5 hp
HP @ 3 Phase - 575V	7 1/5 hp
Hz	50/60
Item	IEC Magnetic Contactor
Item Number	AF09R-30-22-13
Manufacturer	ABB
Manufacturer Part Number	AF09R-30-22-13
Max HP 200/208V 3PH	2 hp
Max HP 230/240V 3PH	2 hp
Max HP 460/480V 3PH	5 hp
Max HP 575/600V 3PH	7.5 hp
Mounting type	Front/Side
Mounting Type	DIN Rail Mount ; Panel .
Net Weight	1.46 lbs
Nominal Coil Voltage	110 VDC, 120 VAC, 240 V.
Number of Auxiliary Con.	2NO-2NC
Number of Poles	3
Operating Temperature	-60 to 80
Poles	3NO
Product Series	AF
Reversing	Yes
Series	AF Series, AF09R
Standards	CSA, IEC, UL
Terminal Type	Screw, Screw Terminal
Termination	Screw Terminal
Type	IEC Contactor
UPC Code	804325862400
Wattage	5.5
Width	3.98 in

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	Airline Hydraulics	ABB AF09R-30-22-13	149.78	1	In Stock		ABB		149.78 @ 1
	standardelectricsupply.com	2263740	150.51	1	In Stock		ABB		150.51 @ 1
	us.rs-online.com	71160329	185.62	1	1		ABB		185.62 @ 1
	Newark	60Y1536	186.63	1	In Stock		ABB		186.63 @ 1
	Galco	AF09R-30-22-13-ABBG	197.73	1	In Stock		ABB	1.725	197.73 @ 1
	Zoro	G2263177	422.34	1	In Stock	17	Abb	1.65	422.34 @ 1
