- mpnHT453
- brandname: Liberty Pumps
- manufacturername: Liberty Pumps
1/2 HPSubmersible Pump,180F
- Brand: Liberty Pumps
- PartNumber: HT453
- Model: HT453
- PackageQuantity: 1
- Binding: Misc.
- Manufacturer: LIBERTY PUMPS
- Label: LIBERTY PUMPS
Attributes
| Key | Value |
|---|
| ADA Compliant | No |
| AMP | 7.3 |
| Amperage Rating | 7.3 A |
| Automatic Shut-Off | Yes |
| Base Diameter | 9-3/5 in |
| Bearing Type | Ball |
| Body Dia. | 9 5/8 in |
| Brand | Liberty Pumps |
| Coating | Powder Coated |
| Connection Type | FPT |
| Cord Length | 10', 10 ft |
| Cord Length - Pumps | 10 ft. |
| Cord Type | SJEOOW |
| Corded Cordless | Corded |
| CSA Certified | CSA 22.2 No. 108 |
| Current Stock | 41 |
| Description: | 1/2 HP, Submersible Hig. |
| Diameter | 9-5/8" |
| Dimensions | 9.6 in W x 12.5 in H |
| Discharge | 1-1/2", 1-1/2 in |
| Discharge Configuration | Vertical |
| Discharge Dia. | 1 1/2 in |
| Discharge NPT | 1-1/2" |
| Energy Star Compliant | No |
| Flow Rate | 53 gpm |
| Frequency Rating | 60 Hz |
| GPM of Water @ 10 Ft. o. | 43 |
| Height | 12-1/2 in, 12-1/2" |
| Horsepower | 1/2 hp |
| Housing Material | ALuminum |
| HP | 4/10, 1/2 |
| Hz | 60 |
| Impeller | Vortex |
| Impeller Material | Engineered Polymer |
| Impeller Type | Vortex |
| International Shipping | No |
| ISO Specifications | ISO 9001 |
| Length | 10-3/4 in |
| MA Approved | Yes |
| Manufacturer | Liberty Pumps, Liberty . |
| Material | ALuminum |
| Max Head | 34' |
| Max. Dia. Solids | 3/8" |
| Max. Diameter Solids | 3/8 in |
| Max. Head | 34.0 ft |
| Max. Temp. | 180 Degrees F |
| Maximum Feet of Head | 34 |
| Maximum Head | 34 ft |
| Maximum Temperature | 180 |
| MFG Part #: | HT453 |
| Min. Sump Pit Dia. | 14 in |
| Minimum Water Depth | 14 in |
| Motor RPM | 3450 |
| Motor Speed | 3450 rpm |
| Motor Type | PSC |
| Mpn | HT453 |
| NSF Certified | No |
| Origin | Domestic |
| Outlet Size | 1-1/2 in |
| Overall Height | 12 1/2 in |
| Part Number | HT453 |
| Phase | 1, 1 ph |
| Product | Sump |
| Product Type | Submersible, High Temp . |
| Pump Body Material | Cast Aluminum |
| Pump Phase | 1 |
| Pump Type | Submersible Pump |
| RPM | 3450 |
| Series | HT450, HT40 Series |
| Shaft Seal | Ceramic, Buna N, Stainl. |
| SKU | ZO-G1403552 |
| SubCategory | Pumps |
| Supplier: | Liberty Pumps Inc |
| Switch | Auto |
| Switch Type | Wide Angle Piggy-Back |
| Temperature Rating | 180, 284 deg F Thermal . |
| Turn On Turn Off Levels | Turn-on 12 in/Turn-off . |
| Type | Automatic High Temperat. |
| UL Listed | UL 778 |
| UPC | 671812114324 |
| UPC: | 671812114324 |
| VAC at 60 Hz | 115 |
| Voltage | 115 |
| Voltage Rating | 115 VAC |
| Volts | 115, 115V |
| Weight | 14 |
| Width | 9 in |
