Martin 3 B 48 TB

B004BKINTK

Martin 3 B 48 TB Conventional Taper Bushed Sheave, A/B Belt Section, 3 Grooves, 1610 Bushing required, Class 30 Gray Cast Iron, 5.15" OD, 4817 max rpm, A - 4.4/B - 4.8" Pitch Diameter

Martin 3 B 48 TB Conventional Taper Bushed Sheave, A/B Belt Section, 3 Grooves, 1610 Bushing required, Class 30 Gray Cast Iron, 5.15" OD, 4817 max rpm, A - 4.4/B - 4.8" Pitch Diameterzoom

Attributes

Key Value
Belt Cross SectionA/B
Bore TypeBushed
Bushed For1610
Bushing Maximum Bore Si.1.5 "
Bushing MountStandard
Bushing StyleTB
Length Through Bore1 "
MaterialSteel
Number of Grooves3
Outer Diameter5.15 in
Outside Dia5.150"
Pitch Diameter4.8 "
Sheave ConstructionSolid
Sheave Face Width2.5 "
Sheave TypeConventional
UPC Code697950154596
Weight6.7 lbs

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
us.rs-online.com7247964895.011In StockMartin Sprocket & Gear6.795.01 @ 1
factorysupplyoutlet.comOG80PQ102.271In Stock25MARTIN102.27 @ 1
thumbzoomapexindustrialautomation.com3 B 48 TB107.391In StockMartin Sprocket107.39 @ 1
thumbzoomMRO Supply254715114.01In StockMartin Sprocket114.0 @ 1
thumbzoomPurvis3 B 48 TB121.81In StockMartin121.8 @ 1
thumbzoomZoroG3336211121.991In StockMartin Sprocket & Gear121.99 @ 1
motionindustries.com00703382129.461In StockMartin129.46 @ 1
